- Page 1 CMB-673 Mini Barebone system Intel Pentium M Platform Installation Guide Edition 1.0 2005/08/20...
- Page 2 CMB-673 Installation Guide Document Content: Packing List Product Specification Hardware Installation Packing List: CMB-673 Chassis x 1 (Including LV-673 Motherboard) SPD-120-12A 120W AC-DC Adapter x 1 Power Cord x 1 CPU Cooler x 1 44-pin to 44-pin ATA33 IDE Cable x1...
- Page 3 CMB-673 Installation Guide Chassis Setup Sequence: 1. Screw up in Back of plastic panel. 2. Screw up the HDD bay .
- Page 4 CMB-673 Installation Guide 3. Please take out the HDD drive bay. 4. Please pull out the USB , Audio and JFRNT cable .
- Page 5 CMB-673 Installation Guide 5. Please screw up the motherboard then take it out of Chassis . After install CPU please screw up the CPU FAN .
- Page 6 CMB-673 Installation Guide 7. Please install LV-673 on the chassis then connect to USB , Audio and JFRNT cable . 8. Before install HDD drive bay on the chassis , please screw up HDD drive .
- Page 7 CMB-673 Installation Guide 9. Please screw up the HDD bay and connect SYS FAN cable on the CN_SYSFAN . 10. Please screw up the VGA card .
- Page 8 CMB-673 Installation Guide 11. Please install the CD-ROM bay with chassis shell on . 12. Please screw up in back of plastic panel .
-
