- Page 1 CMB-679 Mini Barebone system Intel High Performance Platform Installation Guide Edition 1.21 2025/02/03...
-
Page 2: Document Content
CMB-679 Installation Guide Document Content: Packing List Product Specification Hardware Installation Packing List: CMB-679 Chassis x 1 (Including LV-679 Motherboard) DSPD-080-12 80W AC-DC Adapter x 1 Power Cord x 1 CPU Cooler x 1 44-pin to 44-pin ATA33 IDE Cable x1... - Page 3 CMB-679 Installation Guide Notes: You need to have a slim type CD ROM drive to fit into CMB-679. You might also need a convert board to connect the CD ROM drive to the motherboard. This depends on the interface of the CD ROM and its matching interface of the motherboard.
-
Page 4: Hardware Installation
Motherboard placement CN_SMBUS SATA3 CN_USB1/2 SATA2 SATA1 JRTC JVSSD DC-IN JFRNT SYSFAN Mini-PCI1/2 CPUFAN SO-DIMM2 CN_DIO CN_IR NBFAN JCSEL1 CN_LVDS CN_INV CN_DVI1/2 CN_AUDIO CD_IN JVLC CN_COM2 JCSEL2 CN_HDTV For the Components placement,it is available for CMB-679 only For Jumper For Connector... - Page 5 CMB-679 Installation Guide I/O panel: Front: CD-ROM HD LED Reset Button Power LED Power Button MIC Ear-Phone...
- Page 6 CMB-679 Installation Guide Rear: COM2 LAN RJ45 Antenna Port Terminal Block S/PDIF Keyboard IEEE1394 DC-IN CS-Out Line-In COM Port Mouse RS-Out Line-Out SS-Out Mic Power input :DSPD-080-12 80W 12V AC-DC Adapter or Terminal Block 12V DC Input.
- Page 7 CMB-679 Installation Guide Chassis Setup procedure: 1. Turn the chassis screws.
- Page 8 CMB-679 Installation Guide 2. Turn the screws and refer the picture A, B and C.
- Page 9 CMB-679 Installation Guide 3. Push the Chassis shield towards the back then open it.
- Page 10 CMB-679 Installation Guide Turn the screws.
- Page 11 CMB-679 Installation Guide Push the front panel towards the front then take the CD-ROM holder off.
- Page 12 CMB-679 Installation Guide Turn the CPU cooler screws and then refer the motherboard manual page.16 to install the CPU. (After installing CPU, please turn the CPU FAN screws to tighten.)
- Page 13 Open the Dimm holder then check the pin number to match the socket side well before installing memory module.
- Page 14 CMB-679 Installation Guide Press down the memory module then check dimm holder hook well.
- Page 15 CMB-679 Installation Guide 9. Turn the PCI port shield’s screw and take shield off refer picture A and F. (If you don’t install PCI card, please direct to Step 10 .) (A). (B). You can install Riser-Card PCI-2P1 PCI card.
- Page 16 CMB-679 Installation Guide (C). please direct to install Riser-Card and Turn the chassis screws. (D). please direct to install PCI Card...
- Page 17 CMB-679 Installation Guide (E). (F).
- Page 18 CMB-679 Installation Guide 10. After install HD driver, Turn the CD-ROM holder and front panel screw well refer picture.
- Page 19 CMB-679 Installation Guide 11. Turn the CD-ROM driver screws and IDE connector well. ( can be use SATA,IDE or USB interface Slim type CD-ROM to Install but COMMELL doesn’t provide the CD-ROM converter module )
- Page 20 CMB-679 Installation Guide 12. Turn the CD-ROM driver screws and IDE cable connects well. Pin 1...
- Page 21 CMB-679 Installation Guide 13. After install HD driver, Turn the CD-ROM holder and front panel screw well. refer picture A and B. (A). (B).
- Page 22 CMB-679 Installation Guide 14. Turn the CD-ROM driver screws and IDE cable connects well.
- Page 23 CMB-679 Installation Guide 15. Find out the HD holder to install HD driver, it is under backside of the CD-ROM holder.
- Page 24 CMB-679 Installation Guide 16. Put on HD driver into HD holder then turn the HD drive screws to tighten.(If you don’t have HD drive please direct to step.18)
- Page 25 CMB-679 Installation Guide 17. Connect IDE or SATA cable from motherboard to the HD drive.
- Page 26 CMB-679 Installation Guide 18. Turn the CD-ROM driver screws and IDE cable connects well. 19. Turn the chassis shield screws to tighten well.
- Page 27 CMB-679 Installation Guide CF card Setup Procedure: Turn the CF chassis shield screw. Take CF chassis shield off.
- Page 28 CMB-679 Installation Guide Follow the Idiot-proof design then insert the CF card, Check connected well. Close CF chassis shield and turn screw to tighten.
- Page 29 CMB-679 Installation Guide Addendum Notice Please leave the JCFSEL for Master mode, and set the IDE2 HDD as Slave mode if you need to use the CF card. Jumper: JCFSEL Type: onboard 3-pin header JCFSEL Mode Master Slave Default setting...
-
