- Page 1 CBP-6P3X2 PICMG1.3 Half-size Backplane User’s Manual Edition 1.0 2014/08/15...
- Page 2 CBP-6P3X2 User’s Manual Copyright Copyright 2014, all rights reserved. This document is copyrighted and all rights are reserved. The information in this document is subject to change without prior notice to make improvements to the products. This document contains proprietary information and protected by copyright. No part of this document may be reproduced, copied, or translated in any form or any means without prior written permission of the manufacturer.
-
Page 3: Product Specification
CBP-6P3X2 User’s Manual <Product Specification> General Specification Form Factor PICMG1.3 Half size Backplane Extended Interface 1 x PCIe x16 slot, 1 x PCIe x 1 slot, 3 x PCI slot Power Requirement Standard 24-pin ATX power supply Dimension 176 x 142 mm The specifications may be different as the actual production. - Page 4 CBP-6P3X2 User’s Manual <Mechanical Drawing>...
-
Page 5: Jumper Reference
CBP-6P3X2 User’s Manual <Jumper reference> PRBT2 Mode PWRBTN RESET JPCI66_33M Mode Enable the PCI Interface for 66-MHz operation The PCI Interface for 33-MHz operation Default setting: 2-3 JPCI33_66M PRBT2... - Page 6 19F., No.94, Sec. 1, Xintai 5th Rd., Xizhi Dist., New Taipei City Address 22102, Taiwan +886-2-26963909 +886-2-26963911 Website http://www.commell.com.tw info@commell.com.tw (General Information) E-Mail tech@commell.com.tw (Technical Support) Facebook https://www.facebook.com/pages/Taiwan-Commate-Computer-Inc/547993955271899 Twitter https://twitter.com/Taiwan_Commate Commell is a brand name of Taiwan commate computer Inc.
