- Page 1 CBPE-1X2P PICMG1.3 Half-size Backplane User’s Manual Edition 1.0 2016/11/04...
- Page 2 CBPE-1X2P User’s Manual Copyright Copyright 2016, all rights reserved. This document is copyrighted and all rights are reserved. The information in this document is subject to change without prior notice to make improvements to the products. This document contains proprietary information and protected by copyright. No part of this document may be reproduced, copied, or translated in any form or any means without prior written permission of the manufacturer.
- Page 3 CBPE-1X2P User’s Manual <Mechanical Drawing>...
- Page 4 CBPE-1X2P User’s Manual <Product Specification> General Specification Form Factor PICMG1.3 Half size Backplane Extended Interface 1 x PCIe x16 slot, 2 x PCI slot Power Requirement Standard 24-pin ATX power supply Dimension 175.07 x 96.39 mm The specifications may be different as the actual production.
- Page 5 CBPE-1X2P User’s Manual < Power Input > CN_12V Connector: ATX Connector Type: Main power 24-pin connector (as input) Signal Signal 3.3V 3.3V 3.3V -12V PSON POWER_OK 5VSB 3.3V...
- Page 6 CBPE-1X2P User’s Manual Connector: CN_12V Connector Type: ATX12V 4-pin connector Signal Signal “CN_12V” for increase the current input. Power Switch & FAN < > Connector: JPBT Connector Type: Panel Switch 4-pin header JPBT Signal Power Button Reset Connector: FAN Connector Type:...
-
Page 7: Contact Information
Taiwan Commate computer Inc. 19F., NO.94, Sec. 1, Xintai 5 Rd., Xizhi Dist., New Taipei Address City 22102, Taiwan. +886-2-26963909 +886-2-26963911 Website www.commell.com.tw info@commell.com.tw (General information) E-mail tech@commell.com.tw (Technical Support) Commell is a brand name of Taiwan Commate computer Inc.
