- Page 1 CMB-379 Mini Barebone system Intel High Performance Platform Installation Guide Edition 1.01 2025/02/07...
-
Page 2: Table Of Contents
CMB-379 Installation Guide Index Chapter 1 < Packing List > ................4 Chapter 2 < Product Specification >............... 6 2.1< Motherboard placement >..............6 2.2< Jumper Location & Reference > ............9 2.2.1 < JAT >....................9 2.2.2 < JRTC >.................... 9 2.2.4 <... - Page 3 CMB-379 Installation Guide 3.1 < Chassis Setup procedure > ............... 19 < Memory Setup>..................20 3.1.2 < Memory Setup >................20 Contact Information ..................26...
-
Page 4: Document Content
Chapter 2: Product Specification Chapter 3 : Hardware Installation Chapter 1 < Packing List > CMB-379 Chassis x 1 (Including LE-379 Motherboard) DSPD-080-12A 80W AC-DC Adapter x 1 DVI Adapter x1 & DVI Cable x1 COM PORT Cable x 2... - Page 5 CMB-379 Installation Guide SATA Cable x 1 SATA Power Cable x 1 AUDIO Cable x 1 DC_IN Power Cable x 1...
-
Page 6: Chapter 2 < Product Specification
CMB-379 Installation Guide Chapter 2 < Product Specification > 2.1< Motherboard placement > CN_DVI CN_SATA1 CN_SATA2 CN_AUDIO JRTC JCSEL1 JCSEL2 Battery CN_USB1/2 JP1 JP2 CN_IR JFRNT... - Page 7 CMB-379 Installation Guide Right : JP1 Left : JP2 JCSEL1 JCSEL2 DC_IN Left : COM 3/4 DC_OUT CN_COM2 Right : COM 5/6...
- Page 8 CMB-379 Installation Guide SO-DIMM CFast RJ45 COM1...
-
Page 9: Jumper Location & Reference
CMB-379 Installation Guide 2.2< Jumper Location & Reference > Jumper Function AT/ATX Power mode select JRTC CMOS Operating/Clear Setting Com4 Voltage Setting(For Pin 9) Com3 Voltage Setting(For Pin 9) JCSEL1 CN_COM2 RS-232 RS422 RS485 Setting / CN_IR IrDA JCSEL2 Setting 2.2.1 <... -
Page 10: Jp1 (Com 4) & Jp2 (Com 3)
CMB-379 Installation Guide 2.2.4 < JP1 (COM 4) & JP2 (COM 3) > Jumper: JP1 (COM 4) & JP2 (COM 3) Type: onboard 6-pin header Power Mode Pin9 with 5V signal Pin9 with 12V signal HS_RI2-(HS_RI1-) Default setting: 5-6 2.3< Serial Port Jumper Setting >... -
Page 11: Cn_Com3/4
CMB-379 Installation Guide < Setting RS-232, RS-422, RS-485 & IrDA > Function JCSEL1 JCSEL2 IrDA RS-422 RS-485 RS-232 2.3.2 < CN_COM3/4 > Connector: CN_COM3/4 Type: 20-pin (10 x 2) 1.27mm x 2.54mm-pitch header for COM3/4 Description Description HS_DCD1- HS_RXD1 HS_TXD1... -
Page 12: Motherboard Internal Connectors
CMB-379 Installation Guide 2.4<Motherboard Internal Connectors > Connector Function Remark SO-DIMM 204 -pin DDR3 SO-DIMM SDRAM slot CN_SATA 10-pin SATA Cable connector CFast CFast Card socket MINI_CARD PCIE mini card socket MINI_PCI mini PCI socket CN_LVDS 20 -pin LVDS connector... -
Page 13: Pin Assignment
CMB-379 Installation Guide 2.6< Pin Assignment > 2.6.1 < IrDA Port > Connector: CN_IR Type: 5-pin header for SIR Port Description IRRX Ground IRTX 2.7< Indicator and Switch > 2.7.1 < JFRNT > The JFRNT provides front control panel of the board, such as power button, reset and beeper, etc. -
Page 14: Interface
CMB-379 Installation Guide 2.8< Interface > 2.8.1 < DVI Interface > The board also comes with a DVI interface. Supports up to 1920 x 1080 (WUXGA) of resolution. Type: onboard 20-pin connector for DVI connector Connector model: HIROSE DF13-20DP-1.25V Pin Number... -
Page 15: Onboard Audio Interface
CMB-379 Installation Guide 2.8.2 < Onboard Audio Interface > The board provides the onboard high definition audio with Realtek ALC888 Connector: CN_AUDIO Type: 10-pin (2 x 5) 1.27mm x 2.54mm-pitch header Description Description MIC2_L AGND MIC2_R AVCC FRO_R MIC2_JD F_IO_SEN... -
Page 16: Power Connector
CMB-379 Installation Guide 2.9< Power Connector > 2.9.1 < Power Input > Connector: DC_IN Type: 4-pin header Description Description Ground +12V Ground +12V Remark: DC input voltage range 5~24V 2.9.2 < Power Output > Connector: DC_OUT Type: 4-pin connector for +5V/+12V... -
Page 17: I/O Panel
CMB-379 User’s Manual 2.10< I/O panel > 2.10.1 < Front > Power Button HD LED Power LED... -
Page 18: Rear Panel
CMB-379 User’s Manual 2.10.2 < Rear panel > COM2 COM3 COM4 COM1 PS/2 Audio/Mic... -
Page 19: Chapter 3 < Hardware Installation
CMB-379 User’s Manual Chapter 3 < Hardware Installation > 3.1 < Chassis Setup procedure > 1. Screw off as indication of the picture below, Push the Chassis shield towards the back then open it. - Page 20 CMB-379 User’s Manual < Memory Setup> 3.1.2 < Memory Setup > Non-ECC, unbuffered memory is supported only. The board provides one 204-pin DDR3 SO-DIMM to support DDR3 800/1066 memory modules up to 4GB. Suggestion: DDR3 SO-DIMM Modules: –Raw Card C = Single-sided x 8 –Raw Card F = Double-sided x 8...
- Page 21 (1). Insert the DDRII SO-DIMM module into the socket at 45 degree. (2). Press down the module with a click sound.
- Page 22 CMB-379 User’s Manual (3). Put on HDD driver into HDD holder. (4). Then turn the HDD driver screws to tighten with Chassis shield towards the back.
- Page 23 (5). Connect SATA cable and SATA Power cable from motherboard to the HD drive.
- Page 24 CMB-379 User’s Manual (6). the Chassis shield back and screw on as indication of the picture below Turn the screws.
- Page 25 6. Finish...
-
Page 26: Contact Information
New Taipei City, Taiwan +886-2-26963909 +886-2-26963911 Website T U h ttp://www.commell.com.twU T T U i nfo@commell.com.twU T (General Information) E-Mail T U t ech@commell.com.twU T (Technical Support) Facebook https://www.facebook.com/pages/Taiwan-Commate-Computer-Inc/547993955271899 Twitter https://twitter.com/Taiwan_Commate Commell is a brand name of Taiwan Commate Computer Inc.
