- Page 1 FS-A79 PICMG 1.3 Full-size CPU card User’s Manual Edition 1.0 2018/10/30...
- Page 2 FS-A79 User’s Manual Copyright Copyright 2018, all rights reserved. This document is copyrighted and all rights are reserved. The information in this document is subject to change without prior notice to make improvements to the products. This document contains proprietary information and protected by copyright. No part of this document may be reproduced, copied, or translated in any form or any means without prior written permission of the manufacturer.
- Page 3 FS-A79 User’s Manual Packing List: Please check the package content before you starting using the board. 1 x FS-A79 PICMG 1.3 Full-size CPU Card motherborad 1 x VGA Cable 1 x Driver CD and Mini card screw (OALVGA-S-7) / (1040556) (Including User’s Manual)
-
Page 4: Table Of Contents
FS-A79 User’s Manual Index Chapter 1 <Introduction>............... 4 1.1 <Product Overview>............4 1.2 <Product Specification> ............5 1.3 <Block Diagram>..............6 Chapter 2 <Hardware setup>............7 2.1 <Connector Location and Reference> ........ 7 2.1.1 <Internal connectors list> ..........8 2.1.2 <External connectors list>.........8 2.2 <CPU and Memory Setup>... -
Page 5: Chapter 1
FS-A79 User’s Manual Chapter 1 <Introduction> 1.1 <Product Overview> FS-A79 is PICMG 1.3 Full-size CPU Card motherborad which supports 8th generation Intel® Core™, Pentium® and Celeron® processor families (Coffee Lake S) with Intel® Q370 Chipset, integrated HD Graphics , DDR4 memory, Realtek High Definition Audio, Intel Gigabit LAN, Serial ATA3 Intel Coffee Lake-S Processor with Intel®... -
Page 6: Product Specification
FS-A79 User’s Manual 1.2 <Product Specification> System 8th generation Intel® Core™, Pentium® and Celeron® processor , Processor FCLGA1151 package (Support up to 65W TDP) Chipset Intel® Q370 2 x DDR4 DIMM 2666 MHz up to 32GB, Memory Support Non-ECC, unbuffered memory only... -
Page 7: Block Diagram
FS-A79 User’s Manual 1.3 <Block Diagram>... -
Page 8: Chapter 2
FS-A79 User’s Manual Chapter 2 <Hardware setup> 2.1 <Connector Location and Reference> CPUFAN SYSFAN CN_12V DDR4_A DDR4_B CN_LVDS CN_DVI2 CN_DVI1 CN _USB2-1 CN _USB2-2 CN _USB3-1 CN _USB3-2 CN _USB3-3 SATA3-1 SATA3-2 SATA3-3 CN_DIO CN_COM6 CN_COM5 MINI_CARD CN_COM4 SIMM CN_COM3... -
Page 9: Internal Connectors List
FS-A79 User’s Manual 2.1.1 <Internal connectors list> Connector Function DDR4_A/B 288-pin DDR4 DIMM slot SATA3-1/2/3 7-pin Serial ATA3 connector CN_AUDIO 5 x 2-pin audio pin header CN_LPC 6 x 2-pin LPC pin header CN_LVDS 20 x 2-pin LVDS connector CN_INV... -
Page 10: Cpu And Memory Setup
FS-A79 User’s Manual 2.2 <CPU and Memory Setup> 2.2.1 <CPU installation> FS-A79 has a LGA1151 CPU socket onboard; please check following steps to install the processor properly. Attention If FS-A79 needs RMA please Keep CPU socket cover on the CPU Socket. -
Page 11: Memory Setup
FS-A79 User’s Manual 2.2.2 <Memory Setup> FS-A79 has two 288-pin DDR4 DIMM support up to 32GB of memory capacity and 1.2 Voltage. The memory frequency supports 2666 MHz. Only Non-ECC memory is supported. (Core i3, Pentium, Celeron CPU support 2400 MHz only) Please check the pin number to match the socket side well before installing memory module. -
Page 12: Jumper Location And Reference
FS-A79 User’s Manual 2.3 <Jumper Location and Reference> JVLCD JVUSB JVSATA JCSEL1 JCSEL2 JMSATA JCSEL4 JCSEL3 JRTC 2.3.1 <Jumper list> Jumper Function Power mode select JRTC CMOS Normal/Clear Setting JVLCD Panel Voltage Setting JMSATA MiniCard MSATA Setting JCSEL1 COM1 RS-232 RS422 RS485 Setting... -
Page 13: Clear Cmos And Power On Type Selection
FS-A79 User’s Manual 2.3.2 <Clear CMOS and Power on type selection> The board’s data of CMOS can be setting in BIOS. If the board refuses to boot due to inappropriate CMOS settings, here is how to proceed to clear (reset) the CMOS to its default values. -
Page 14: Ethernet Interface
FS-A79 User’s Manual 2.4.2 <Ethernet interface> The board provide I219-LM PHY Gigabit Ethernet and I210-AT Gigabit Ethernet on rear I/O.Intel I219-LM and I210 supports operation at 10/100/1000 Mb/s data rates, with IEEE802.3 compliance and Wake-On-LAN supported. I219-LM I210-AT 2.4.3 <Display interface>... - Page 15 FS-A79 User’s Manual CN_DVI2 CN_LVDS CN_DVI1 JVLCD CN_INV CN_CRT -14-...
- Page 16 FS-A79 User’s Manual CN_CRT: VGA 16-pin connector (Pitch 2.00 mm) Signal Signal IOGND1 IOGND1 IOGND1 IOGND1 IOGND1 5VCDA 5HSYNC 5VSYNC 5VCLK CN_LVDS: LVDS 40-pin connector ( Model: HIROSE DF13-40DP-1.25V compatible Signal Signal Set by JVLCD Set by JVLCD Detect (Active low)
- Page 17 FS-A79 User’s Manual CN_INV: LVDS 5-pin Backlight power connector Signal Backlight Control Enable Backlight JVLCD: LVDS panel power select jumper Jumper settings Function 3.3V (Default) CN_DVI1/2: 20-pin header Pin Number Assignment Pin Number Assignment Ground TMDSTX0N TMDSTX0P Ground TMDSTX1N TMDSTX1P...
-
Page 18: Serial Port Interface
FS-A79 User’s Manual 2.4.4 <Serial Port interface> JCSEL4 JCSEL1 CN_COM1/2/3/4/5/6 JCSEL2 JCSEL3 COM1: RS232/422/485 9-pin header Signal Signal DCD/ 422TX-/ 485- RXD/ 422TX+/ 485+ TXD/ 422RX+ DTR/ 422RX- Set by JP1 Note: Use JCSEL1 and JCSEL3 select communication mode -17-... - Page 19 FS-A79 User’s Manual COM2: RS232/422/485 9-pin header Signal Signal DCD/ 422TX-/ 485- RXD/ 422TX+/ 485+ TXD/ 422RX+ DTR/ 422RX- Set by JP2 Note: Use JCSEL2 and JCSEL4 select communication mode COM3/4/5/6: RS232 9-pin header Description Description JCSEL1 / 3, JCSEL 2/ 4: For configure COM1 &COM2 communication mode...
-
Page 20: Usb Interface
FS-A79 User’s Manual 2.4.5 <USB interface> JVUSB CN_USB2-1/2 CN_USB3-1/2/3 CN_USB 2-1/2-2: USB2.0 10-pin header (Pitch 2.54 mm) Signal Signal 5VSB 5VSB DATA0- DATA1- DATA0+ DATA1+ CN_USB3-1/3-2/3-3 USB3.1 20-pin header (Pitch 2.00 mm) Description Description (5V_SB/ 5V) USB3.1_RX0- (5V_SB/ 5V) USB3.1_RX0+ USB3.1_RX1-... -
Page 21: Audio Interface
FS-A79 User’s Manual JVUSB: 6-pin Power select jumper Description 1-3 & 2-4 5V_SB (Default) 3-5 & 4-6 1.Effective patterns of connection: 1-3 & 2-4 or 3-5 & 4-6 2.JVUSB can control CN_USB3-1/2/3 2.4.6 <Audio interface> CN_AUDIO CN_AUDIO: Front panel audio 10-pin header (Pitch 2.54mm) -
Page 22: Expansion Slot
FS-A79 User’s Manual 2.4.7 <Expansion slot> JMSATA MINI_CARD SIMM MINI_CARD have some special design to compatible our mini-PCIe card. (ex: MPX-574D2, MPX-210D2 etc) MINI_CARD support mSATA by JMSATA, and connect SIM card with 3G module. JMSATA: Setting MINI_CARD to support PCIe/mSATA... -
Page 23: Front Panel Switch And Indicator
FS-A79 User’s Manual 2.4.8 <Front panel switch and indicator> JFRNT JFRNT: Front panel switch and indicator 14-pin header (Pitch 2.54mm) Signal Signal HDD_LED+ Power_LED+ HDD_LED- Reset+ Power_LED- Reset- Speaker+ Power_ON+ Power_ON- Speaker- -22-... -
Page 24: Gpio And Other Interface
FS-A79 User’s Manual 2.4.9 <GPIO and Other interface> SYSFAN CPUFAN CN_DIO CN_SMBUS CN_LPC -23-... - Page 25 FS-A79 User’s Manual When using GPIO function Press Delete to enter BIOS Setup menu On Front Page screen, click Setup Utility On Advenced screen, click SIO NCT6116D,then click GPIO 4 Configuration Internal Resistance: Select output type, Push pull or Open drain...
- Page 26 FS-A79 User’s Manual CN_DIO: GPIO 12-pin header (Pitch 2.00mm) Signal Signal GP40 GP44 GP41 GP45 GP42 GP46 GP43 GP47 CN_LPC: LPC 12-pin header (Pitch 2.00mm) Signal Signal -LFRAME LAD3 LAD2 LAD1 LAD0 3.3V SERIRQ 3.3VSB CN_SMBUS: SMBus 5-pin connector (Pitch 2.54mm)
-
Page 27: Power Supply
FS-A79 User’s Manual 2.5 <Power supply> 2.5.1 <Power input> CN_12V CN_12V: ATX12V 4-pin connector Signal Signal -26-... -
Page 28: Appendix A
FS-A79 User’s Manual Appendix A <Flash BIOS> A.1 <Flash tool> The board is based on Insyde BIOS and can be updated easily by the BIOS auto flash tool. You can download the tool online at the address below: FPT Tool The tool’s file name is “FPT.exe”, it’s the utility that can write the data into the... -
Page 29: Appendix B
FS-A79 User’s Manual Appendix B <LCD Panel Type select> According your panel, it need to select the correct resolution in the BIOS. If there is no fit your panel type, please feedback for us to make OEM modol. Find the setting from Front Page->... - Page 30 FS-A79 User’s Manual Advanced SA configurationGraphics confuguration LCD controlLCD Panel Type There are 16 resolutions in LCD Panel Type. (For Dual boot and Legacy boot) -29-...
-
Page 31: Appendix C
FS-A79 User’s Manual Appendix C <Programmable Watch Dog Timer> The watchdog timer makes the system auto-reset while it stops to work for a period.The integrated watchdog timer can be setup as system reset mode by program.You can select Timer setting in the BIOS, after setting the time options, the system will reset according to the period of your selection. - Page 32 FS-A79 User’s Manual Timeout value range 1 to 255 Minute and Second Program sample Watchdog timer setup as system reset with 5 second of timeout -o 4E 87 ;enter configuration -o 4E 87 -o 4E 07 -o 4F 08 ;select Logical Device...
-
Page 33: Appendix D
FS-A79 User’s Manual Appendix D <Hardware Monitor> Find the setting from AdvancedSIO NCT6116DHardware Monitor -32-... -
Page 34: Appendix E
FS-A79 User’s Manual Appendix E <Programmable GPIO> The GPIO’ can be programmed with the MS-DOS debug program using simple IN/OUT commands. GPIO -o 4E 87 ;enter configuration -o 4E 87 -o 4E 07 -o 4F 07 ;select Logical Device -o 4E 30 -o 4F 10 ;activate GPIO function (The board use GPIO4) -
Page 35: Appendix F
FS-A79 User’s Manual Appendix F <RAID Setting> When use RAID function, it need to enter the BIOS set RAID mode first. Advanced PCH-IO Configuration SATA and RST Configuration SATA Mode Selection At boot time, press <CTRL + I> to enter the RAID configuration menu. -
Page 36: Contact Information
Taiwan Commate computer Inc. 19F., NO.94, Sec. 1, Xintai 5 Rd., Xizhi Dist., New Taipei Address City 22102, Taiwan. +886-2-26963909 Website www.commell.com.tw info@commell.com.tw (General infomation) E-mail tech@commell.com.tw (Technical Support) Commell is a brand name of Taiwan Commate computer Inc. -35-...
