Shutter On/Off Time 2; Time Lapse - Cognisys STACKSHOT 3X Owner's Manual

8.5.6 Shutter On/Off Time 2+

If (and only if) the "Pics Per Move" is set to greater than one, this on/off time determines how
long the shutter output will be on or off for the second and subsequent shutter activations.

8.6 Time Lapse

The "Time Lapse" interval determines the time between executing the current operating mode.
What does that mean? If you're in a stacking mode, this setting will execute that stack at this
interval. If you were in the "Motion: Time Lapse" mode, you could execute that mode at this
interval (a time lapse within a time lapse!). When set to "off" (zero seconds) the controller
functions normally – just one execution for a stack/pan/motion. If the time is set to a value
other than "off", time lapse mode is enabled. This feature allows the periodic capture of a
sequence of images. An example where this may be helpful would be stacking a flower
blooming over time.
As soon as you start time lapse, the screen for the mode you are currently in will change to the
"Time Lapse" screen:
Here you can see the number of times an event has completed (A stack, pan, or motion profile).
There is a count-down timer until the next event begins.
At the bottom of the screen you will see the status of the three axes. There are three states:
<inactive> -- This axis is not used in the current configuration
Running – This axis is currently performing an operation
Waiting – This axis is waiting to perform an operation (you'll see this between time lapse events
as well).
