3. Basic Navigation

In this section we'll go into the basics of adjusting settings for StackShot 3X. If you find your
eyes glossing over with all the technical discussion you can always skip to the "10 - Examples"
section to start using StackShot 3X.

3.1 Common Icons

There are several icons you will see on the StackShot 3X screen. Their behavior is consistent
regardless of what mode you are in or what you are doing.
Take me home! It will always take you to the main screen for whatever mode you are currently
in. It doesn't matter if you're five screens deep and have found yourself somewhere spooky –
this will take you home in a hurry.
Change settings. Most importantly this is where you go to change what operating mode you're
using. Beyond that you can adjust pretty much any setting -- from Wi-Fi settings to gear ratios.
or...
Change axis. If you're using a mode that lets you adjust different behavior for each axis, this
will change which axis you are working with. The "X" indicates you're working on the X-axis.
Move axes. If you touch this icon you will be able to adjust all three axes in one place. As
mentioned above, the speed and direction depends on where you put your finger. You can
slide up and down to adjust the move speed.
X
