Activate Camera. This will activate the camera output(s). You can adjust which output this
activates in section "8.4 - Settings". The output will behave as configured in section "8.5 -
Shutter Output Settings". When the outputs are active there will be a red-circle with the output
number shown on top of this camera icon.
Adjust position. This will allow you to control the position of the current axis. The further you
move along the slider the faster the motor will move. Above the center dot is forward, below is
backward.
Scroll up/down. This lets you scroll through all the settings. If there are more settings available,
you will see a scroll-bar on the right-hand side of the screen showing how far you are into the
list of settings.
Return to the previous menu. This will take you back just one screen. The "home" button will
take you all the way to the main screen.
