berbel
Island Hood BIH 60 CB

Operating Instructions

10/2009
English version of original German instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BIH 60 CB and is the answer not in the manual?

Questions and answers

Related Manuals for Berbel BIH 60 CB

Summary of Contents for Berbel BIH 60 CB

  • Page 1: Operating Instructions

    Island Hood BIH 60 CB Operating Instructions 10/2009 English version of original German instructions...
  • Page 2 These instructions help you to use our product properly, safely and economically. In the following The illustrations contain portrayals in various grey text, our berbel island extractor hood BIH 60 CB scales. Movements which are to be carried out are product is briefly referred to as device.

  • Page 3: Table Of Contents

    Maintaining the device ............................23 Maintaining the lighting .............................23 Replacing the filter filling (hybrid and recirculating air filters) ................23 Rectifying malfunctions ..........................30 Disposal.................................32 Disposing of packaging.............................32 deviceDisposal..............................32 Technical data ...............................33 Model plate ...............................33 Island Hood BIH 60 CB.............................33 Contacting the manufacturer..........................34...

  • Page 4: Safety

    • Check the device and all parts for visible damage. In the event of damage, contact your specialist Proper use dealer or the berbel customer service. The device must only be used in flawless condition. The device can be used to extract cooking vapours during cooking.
  • Page 5 Safety Avoiding dangers due to electric shock designate a person to prevent the fuse from being switched on. • Have work on the voltage supply carried out by a qualified, trained specialist electrician only. − Allow the device to dry. At the very least, the specialist electrician must −...

  • Page 6: Structural Features Of The Information On Dangers

    Safety The device may only be installed above a fireplace Avoiding environmental damage for solid fuels (e.g. coal-fired stove) if: • Dispose of the device and its accessories • the fireplace has a sealed cover which cannot be according to the legal regulations. removed.

  • Page 7: Structural Features Of Notices Regarding Material Or Environmental Damage

    Safety Structural features of notices regarding material or environmental damage ATTENTION These notices warn of a situation which leads to material or environmental damage.

  • Page 8: Description

    Description Description Cleaning is carried out in several cleaning stages. The first cleaning stage removes e.g. grease and The following illustrations show the way in air particles from the intaken room air. The next which the possible operating modes function. cleaning stage filters light, flying particles (e.g.
  • Page 9 Description Hybrid mode of the intaken room air. The next cleaning stage filters light, flying particles (e.g. fluff) from all of the intaken room air. Whilst part of the cleaned room air is conducted outside, the filter filling in the hybrid filter neutralises odour contents which are present in the remainder of the intaken room air.

  • Page 10: View Of The Device With Flap Closed

    Description View of the device with flap closed Rotary knob (ThinCoder) Flap with lower grease tray   Lighting ...

  • Page 11: View Of The Device With Flap Open

    Description View of the device with flap open Upper grease tray Flap with lower grease tray   "Capillar Trap" ...

  • Page 12: View Of The Device From The Left

    Description View of the device from the left Lock-type mountings for the chimney panel Optional: Recirculating air filter or hybrid filter   Lower brackets for the chimney panel Optional: Ventilation slits   Rotary knob (ThinCoder) Chimney panel  ...

  • Page 13: Operation

    Operation Operation ATTENTION WARNING Fire hazard due to flambéing beneath the device. Danger of suffocation due to a lack of oxygen on operation of the device. Naked flames may e.g. damage neighbouring cupboards. Ensure an adequate fresh air supply in the dwelling. Do not flambé...

  • Page 14: Changing The Output Level

    Operation Switching off the ventilation function Proceed as follows to switch on the device: Turn the rotary knob clockwise from level "0" to Proceed as follows to switch off the ventilation the desired output level. function: The rotary knob engages at each output level. Turn the rotary knob counter-clockwise to the "0"...

  • Page 15: Switching The Lighting On And Off

    Operation Example: Turn the rotary knob to level "0". You have prepared your dish and would like to have the air in the kitchen cleaned for a further ten minutes. You have used the device at the desired output level for at least one minute. Carry out the following activities in direct succession: Turn the rotary knob from the current position to...
  • Page 16 Operation Switching off the lighting Proceed as follows to switch off the lighting: Press gently on the rotary knob with one finger. The lighting is switched off.

  • Page 17: Cleaning

    Cleaning Cleaning Proceed as follows to clean the device in the case of normal soiling: DANGER Open the flap by pulling it downwards at the Fatal electric shock due to fluids which rounded edge. enter the device. Never pour fluids into the device. WARNING Fire hazard due to grease residues in and on the device.

  • Page 18: Cleaning In The Case Of Severe Soiling

    Cleaning Cleaning in the case of severe soiling Grip the grease tray, which is folded down vertically, at the sides using both hands. If the device is severely soiled, the grease trays and the "Capillar Trap" must be removed. These parts Raise the lower grease tray approx.
  • Page 19 Cleaning Pull the "Capillar Trap" off downwards. Release the grease tray by pulling it downwards. In the rear area of the device, the grease tray is seated on the flap guide pins. Lower the front side of the grease tray at an incline (1.).
  • Page 20 Cleaning Installing the upper grease tray Secure the grease tray by pressing it upwards into the device until the locks audibly engage. Grip the upper grease tray using both hands. Make sure that the upper grease tray is inserted Guide the grease tray at an incline into the device correctly.

  • Page 21: Cleaning Surfaces

    Cleaning Insert the "Capillar Trap" into the device by Secure the grease tray by pressing it backwards pressing it firmly upwards. into the device (1.). The "Capillar Trap" does not engage; instead, it is Lower the grease tray. merely clamped in. Make sure that the grease tray is inserted correctly.

  • Page 22: Cleaning The Rotary Knob

    Cleaning Clean surfaces with a soft, moist cloth and a mild Position the rotary knob in the correct installation household cleaning agent. position on the axle. Install the rotary knob by pressing it into the correct position on the axle. Cleaning the rotary knob Removing the rotary knob Pull the rotary knob off.

  • Page 23: Maintenance

    Maintenance is not required. Protect surfaces and devices (e.g. cooled cooker top) beneath your working area from damage, Contact your specialist berbel dealer or the berbel e.g. with thick cardboard. customer service in the event of malfunctions. Removing the chimney panels...
  • Page 24 Maintenance The lower edge of the chimney panel is pushed into Position yourself in front of the left-hand side of the lower brackets (2) from below. the device. Grip the chimney panel in the upper area of the device using both hands. Pull the upper area of the chimney panel (1.) towards yourself.
  • Page 25 Maintenance Lower the chimney panel vertically until it is free. Place the chimney panel down securely in a location outside of the working area. Removing the hybrid filter Proceed as follows to replace the filter filling: Remove the outgoing air line from the sleeve.
  • Page 26 Maintenance Remove the sleeve from the filter. Removing the recirculating air filter Proceed as follows to replace the filter filling: Pull the filter out upwards using the folding handle. Pull the filter out upwards. Replacing the filter filling Replace the filter filling. Replacement of the filter filling is described separately in the operating instructions for the filter filling.
  • Page 27 Maintenance Position the filter on the device from above. Hybrid mode only: Position the sleeve on the filter. The filter is correctly inserted when the lower edge lies fully on the device. Slide the outgoing air line into the sleeve. Make sure that the filter is inserted correctly.
  • Page 28 Maintenance Make sure that the outgoing air line is correctly Fold open the two lock-type mountings (1) by connected. pressing against the sides of the lock-type mountings at the bottom. The filter filling has been replaced. Inserting the chimney panel After replacing the filter filling, the chimney panel has to be inserted.
  • Page 29 Maintenance Guide the lower edge of the chimney panel The lock-type mountings engage in the square behind the lower brackets (1). centring apertures on the upper edge of the chimney panel and hook the chimney panel in. Push the chimney panel upwards (1.) until the Retaining magnets secure the lock-type mountings upper edge of the chimney panel is over the lock- in the final position.

  • Page 30: Rectifying Malfunctions

    Rectifying malfunctions Rectifying malfunctions DANGER Fatal electric shock due to improperly carried out repairs. Make sure that repairs are carried out exclusively by the manufacturer or authorised specialists.
  • Page 31 Replace the filter filling in the hybrid filter. The outgoing air line has not been Contact your specialist berbel dealer or connected or routed properly. the berbel customer service. If a malfunction cannot be rectified, contact your specialist berbel dealer or the berbel customer service.

  • Page 32: Disposal

    Disposal Disposal Dispose of the packaging according to material segregation and in an environmentally-friendly manner. Disposing of packaging DANGER deviceDisposal Danger of suffocation due to parts of the packaging (e.g. films and polystyrene). Store film or other parts of the packaging in a location which is inaccessible to children.

  • Page 33: Technical Data

    • Voltage • Total output • Serial number • Year of construction • Symbols of the legal regulations to which the device adheres and test symbols. Island Hood BIH 60 CB Width 600 mm Depth 430 mm Height 800 mm Max.

  • Page 34: Contacting The Manufacturer

    Contacting the manufacturer Contacting the manufacturer If you have any questions which are not answered by these instructions, contact: berbel Ablufttechnik GmbH Sandkampstraße 100 D-48432 Rheine Telephone +49 (0)800/56 06 06-0* +49 (0)800/56 06 06-1* Internet www.berbel.de *) Free from the German land line...
  • Page 35 © KONTECXT GmbH Technische Dokumentation D-45145 Essen www.technische-dokumentation.de Printed in Germany...
