- Page 1 CHDBT-1H2CE 1×3 HDMI over HDMI and CAT5e/6/7 Splitter with PoE and LAN Serving Operation Manual Operation Manual...
- Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
- Page 4 SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
-
Page 5: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Applications ........... 1 3. Package Contents ........ 1 4. System Requirements ......2 5. Features ..........2 6. Operation Controls and Functions ..3 6.1 Front Panel .........3 6.2 Rear Panel .........4 6.3 IR Cable Pin Assignment ....5 7. -
Page 6: Introduction
1. INTRODUCTION The HDMI Splitter over HDMI and CAT5e/6/7 supports resolutions up to 1080p Full HD, Deep Color, 4K × 2K, 3D and multi-channel digital audio formats such as LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD from Hi-Def sources to an HDMI and 2 CAT5e/6/7 outputs. This splitter has the ability to provide you with simultaneous HDMI and 2 CAT5e/6/7 outputs where the HDMI output can be connected to display or cascaded with another splitter. -
Page 7: System Requirements
4. SYSTEM REQUIREMENTS • HDMI equipped source device, connected with an HDMI cable or DVI equipped source, connected with DVI to HDMI cables • HDMI equipped displays (TVs or monitors) or HDMI equipped AV receivers, connected with HDMI cables • Industry standard CAT5e/6/7 cables •... -
Page 8: Operation Controls And Functions
6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel DC 24V HDMI OUT HDMI IN SERVICE RS232 IN RS232 IN RS232 IN A/B: Connect to a PC/laptop or RS-232 control system (with supplied 3.5mm phone jack to D-Sub 9 pin adaptor) for the transmission of RS-232 commands. -
Page 9: Rear Panel
6.2 Rear Panel IR A1 IR A2 IR B1 IR B2 Extender Extender Blaster Blaster MODE LINK LAN: Connect to an active network for LAN serving. When any compatible LAN equipped receivers are connected, this allows the network access (including internet access if available) to be shared between any connected LAN equipped receivers. -
Page 10: Ir Cable Pin Assignment
6.3 IR Cable Pin Assignment Twin IR Blaster Power 5 V IR Blaster Signal IR Extender IR Signal Power 5 V Grounding... -
Page 11: Connection Diagram
7. CONNECTION DIAGRAM SmartPhone or Tablet DVD/Blu-ray Player Wireless Modem/Router RS-232 Control System HDMI (Internet Input Connection) IR Blaster ('Y' Cable) RS-232 IR Extender Front Rear DC 24V HDMI OUT HDMI IN IR A1 IR A2 IR B1 IR B2 Extender Blaster Extender... -
Page 12: Specifications
8. SPECIFICATIONS Video Bandwidth 300 Mbps/10.2 Gbps Input Ports 1×Female HDMI Type A, 2×3.5 mm RS-232, 2×IR Digital Eyes, 1×LAN (Ethernet),1×USB (Service Only) Output Ports 1×HDMI, 2×CAT5e/6/7, 2×IR Emitters Resolution Uncompressed video Up to 1080p@60 Hz 36-bit plus 4K×2K Power Supply 24 V/2.7 A DC (US/EU standards, CE/FCC/ UL certified) Dimensions... - Page 16 CYPRESS TECHNOLOGY CO., LTD Home page: http://www.cypress.com.tw...
