CYP Clux-8 Operation Manual

1x8 hdmi 1.3 with multi-channel splitter
Hide thumbs Also See for Clux-8:

Advertisement

Table of Contents

CLUX-8
1x8 HDMI 1.3 with
Multi-channel
Splitter
Operation Manual
CLUX-8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Clux-8 and is the answer not in the manual?

Questions and answers

Related Manuals for CYP Clux-8

Summary of Contents for CYP Clux-8

  • Page 1 CLUX-8 1x8 HDMI 1.3 with Multi-channel Splitter Operation Manual CLUX-8...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Introduction................2. Features..................3. Operation Controls and Functions.......... 3.1 Front Panel................3.2 Rear Panel................4. Connection and Installation............. 5. Specifications................

  • Page 3: Features

    Introduction The HDMI v1.3 Distribution Amplifier Series is the most advanced solution to HDMI signal distribution. Each product in this series is compatible with HDMI v1.3 specifications, a cutting-edge technology which defines the support to transfer Deep Color (10-bit and 12-bit) video and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio, with a high bandwidth up to 225MHz (6.75Gbps).

  • Page 4: Operation Controls And Functions

    HDMI OUT SYNC HDMI IN HDMI OUT POWER CLUX-8 HDMI v1.3 SPLITTER DC 5V HDMI Outputs 1/2/3: Connect each of the output ports to the HDMI display. When more than one output connected, the HDMI outputs play identical video signal simultaneously.

  • Page 5: Rear Panel

    3.2 Rear Panel HDMI OUT HDMI OUT HDMI OUT HDMI OUT HDMI OUT EDID EDID Control switch: Default factory setting is TV, leave as is if the display is properly. Switch to STD to use build-in EDID if the display has problems. When the EDID control switch in TV selection, the unit will detect the first HDMI output source’s EDID and record in the unit.

  • Page 6: Connection And Installation

    4. Connection and Installation HDMI Cable DVD or Set-Top-Box HDTV HDMI display LCD TV 5. Specifications Frequency Bandwidth 2.25Gbps (single link) 1x HDMI female port (Type A connector) Input Port 8x HDMI female ports (signal link) Output Ports 5VDC/5A (US/EU standards, CE/FCC/UL certified) Power Supply 240(W) x 103(D) x 24(H) Dimensions (mm)
  • Page 8 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw 20080403 MPM-CLUX8...
