Eliminator Lighting e 139 Operating Instructions

E 139
CAUTION! Please read and
understand these instructions
before installing or operating
this unit.
Operating Instructions:
This unit is a 4 channel DMX intelligent, barrel mirror
scanner. It can be run as a stand-alone, sound active
unit, DMX controlled unit, or in a Master/Slave con-
figuration. This unit also has a color correction filter
inside, so white will be crisp and clear, as if there
was a discharge lamp inside. This unit has been
tested and the lamp has been installed at the factory,
there is no assembly required. The unit is ready to be
plugged in to a power outlet. For dipswitch settings
in stand-alone mode and Master/Slave mode, see
other side. To enhance the beams use this effect with
a fog machine. This unit also looks great in pairs.
Lamp Replacement: Disconnect the units main
power supply. Unscrew and remove the thumb
screws from the bottom half of the scanner. Slide
the lamp socket out to expose the lamp. Remove
and replace the bulb. Reassemble and reconnect
the power supply. Be sure to follow all the handling
instructions that are included with your new lamp.
©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com
SPECIFICATIONS:
Model:
Lamp:
Weight:
Size:
Fuse:
Supply Voltage:
Working Position:
Duty Cycle:
DMX Channels:
Gobos:
Colors:
Warranty:
Caution! Never open unit when in use.
Always disconnect main power before
serving or replacing lamp. Remember to
always replace with the exact same type
lamp and fuse.
HALOGEN LAMP WARNING!
This fixture is fitted with halogen
lamps which are highly susceptible
to damage if improperly handled.
Never touch lamp with bare fingers
as the oil from your hands will short-
en lamp life. Also, never move fixture
until lamp has had ample time to
cool. Remember, lamps are not cov-
ered under warranty conditions.
E 139
EVC/EHJ 24V/250W
23lbs./ 10.4kgs.
6.2" (H) x 10" (W) x
19.4" (L)
5 Amp
120V
Any Safe position
None
4
10
7 Colors + White + 2 Split
Colors
180 Days
