5—PixelNet Domain Configuration

5.3 The Display Wall Configuration Tab

The Display Wall Configuration page displays the following sections:
• Output Nodes:
• Video Tab: List of discovered output nodes
• Audio Tab: List of discovered audio nodes
• Wall Configuration:
• Buttons:
• Display Wall Tabs: Displays wall names (when saved)
54
+
to add a wall,
• Display Wall Name: User defined
• Resolution: Drop-down menu of supported resolutions
• Screens X: Number of horizontal displays
• Screens Y: Number of vertical displays
• Display wall mimic: The mimic (blue rectangles)
represents the display wall in rows and columns as
selected from the Screen X and Y lists.
PixelNet Domain Control User Manual
-
to delete current wall
