5—PixelNet Domain Configuration
Clicking Next before clicking Save, will prompt the following message:
• Click Yes to proceed to
saving the Display Wall Configuration.
• Click No to go back and save the Display Wall Configuration.

5.3.5.2 To assign an Audio node perform the following:

1. In the Output Nodes section, click the Audio tab.
2. From the list of audio nodes, select the audio output node to be
assigned to the wall.
3. Drag and drop the selected audio node in the Audio Window
below the blue rectangles. The Audio Window will display the
assigned audio output nodes with an audio icon followed by the
node name.
92
Source Configuration Tab
PixelNet Domain Control User Manual
