6—PixelNet Domain Control (PDC) Software
• Duplicate: Creates a new file on the operating system with a
unique name, using the original file name as the base. For
instance, <original name>_copy.
• Set as Default: Sets the chosen configuration as the default
configuration to apply on every PDC restart.
Keyboard shortcuts Del, Ctrl-X, Ctrl-D, Ctrl-C, and Ctrl-V are available
through the right-click context menu.
Selecting a specific Domain Configuration from the right of the dialog will
cause it to load during the next PDC startup.

6.5.3 Edit

Clicking on Edit opens the PixelNet Domain Configuration dialog
displaying the Domain Connection tab. Select the Display Wall
Configuration tab where any configuration aspect can be modified.

6.5.3.1 Editing Output Nodes

The Display Wall Configuration tab shown below appears with current
node assignments:
178
Figure 140 - Display Wall Configuration Tab
PixelNet Domain Control User Manual
