A—PixelNet Node Properties
Property
HSync Polarity
VSync Polarity
HSync Rate
Contrast [Mono]
Contrast [Red]
Contrast [Green]
Contrast [Blue]
VSync Rate
HSync Width
VSync Width
Ext Sync
Gen Sync
200
Table 7: DVI Output Property List
Value
1
1
315000
100
100
100
100
6000
96
2
0
0
PixelNet Domain Control User Manual
Description
A horizontal synchronization pulse is
generated whenever the node is
scanning a new line. 1=negative
polarity, 0=positive polarity.
A vertical synchronization pulse is
generated whenever the node scans
a new image from the top of the
screen. 1=negative polarity, 0=posi-
tive polarity.
This denotes the line rate (KHz)
Level of contrast (Gain). Range is 0
to 200.
Level of contrast (Gain). Range is 0
to 200.
Level of contrast (Gain). Range is 0
to 200.
Level of contrast (Gain). Range is 0
to 200.
This denotes the frame rate in centi-
Hertz
Horizontal Sync Pulse
(given in pixels)
Vertical Sync Pulse (given in lines)
Indicates whether External Sync
signal is detected
Generate Genlock Sync. Signal
