6—PixelNet Domain Control (PDC) Software

6.2.5 Displaying a Video Source

Perform the following tasks to display a video source:
1. Select the source icon.
2. Drag and drop it on the display area.
3. Select the window icon on the display wall and drag to position
as needed.
4. Grab the size handles of the window icon and size the window as
needed.
Dragging a source icon and dropping it onto an existing window will
replace the content of the window with the dragged input.
Dragging a source icon on top of another window while holding down the
Control (Ctrl) key will open a new window on top of that window (referred
as picture-in-picture or PIP).

6.2.6 Displaying an Audio Source

Perform the following tasks to display an audio-capable source:
1. Ensure that the Audio menu item is selected under the View
menu (View-->Audio). Otherwise, the Audio Window will remain
hidden.
Note The audio source must have been assigned to the display
wall during the phase when output nodes were assigned to
displays. Unassigned audio nodes can not be displayed
on the Audio Window. To assign an audio node after the
initial configuration phase, Edit (Configuration-->Edit) the
current configuration, save, and load it.
2. Select the audio source icon and drag and drop it on the audio
window area. Non-audio sources can not be dropped on the
audio window; attempting to do so will produce an error icon:
Once an assigned audio node is dropped on the audio window, it
will look like
172
"Figure 132" on page
PixelNet Domain Control User Manual
173.
