A.4 3G-SDI Input Properties
The current property list for 3G-SDI Input is given below. able Legend
• Bolded Rows = Read Only Properties (these cannot be
modified by you)
• Un bolded Rows = Read/Write Properties (these properties can
be modified but do not alter them without sufficient guidance
from Jupiter Systems)
Property
Signal Valid
Auto Detect Enable
Image Width
Image Height
HTotal
VTotal
HActive
VActive
HBackPorch
VBackPorch
HSync Rate
VSync Rate
Brightness [Mono]
206
Table 10: 3G-SDI Property List
Value
States whether a valid signal
1
exists.
1 Performs Auto Detection
Width of input source image (pix-
1280
els)
Height of input source image
720
(lines)
Displays the total horizontal pix-
2000 els that were charted on the video
stream
Displays the total vertical lines
900 that were charted on the video
stream
Displays the active horizontal pix-
1200 els that were charted on the video
stream
Displays the active vertical lines
700 that were charted on the video
stream
This denotes the pixel value of the
400 horizontal segment behind the
HSync marker
This denotes the line value of the
70 vertical segment behind the
VSync marker
This denotes the Frame rate in
0
kHz
This denotes the Frame rate in
0
centiHertz
Level of brightness—All (Offset).
0
Range is -100 to 100.
