Summary of Contents for Barco DP2K-E series
- Page 1 DP2K-E series Safety manual R5906695/00 19/06/2015...
- Page 2 Barco Visual (Beijing) Electronics Co., Ltd 地址：北京市 昌平区 中关村科技园 昌平园 昌盛路 16号 Phone: +86 10 8010 1166 Fax: +86 10 8970 2793 Support: www.barco.com/en/support Visit us at the web: www.barco.com Barco NV President Kennedypark 35, 8500 Kortrijk, Belgium Phone: +32 56.36.82.11 Fax: +32 56.36.883.86...
-
Page 3: General Considerations
“warnings” and “cautions” as well. Clarification of the term “DP2K-E series” used in this document When referring in this document to the term “DP2K-E series” means that the content is applicable for following Barco products: • DP2K-6E Barco provides a guarantee relating to perfect manufacturing as part of the legally stipulated terms of guar- antee. -
Page 4: Owner's Record
The part number and serial number are printed on a label which is stuck on the respective part. Record these numbers in the spaces provided below. Refer to them whenever you call upon your Barco dealer regarding this product. Product article number... -
Page 5: To Prevent Fire Hazard
fire extinguishers. Never use water on an electrical fire. Always have service performed on this projector by authorized Barco service personnel. Always insist on genuine Barco replacement parts. Never use non-Barco replacement parts as they may degrade the safety of this projector. -
Page 6: To Prevent Battery Explosion
If the product exhibits a distinct change in performance, indicating a need for service. • Replacement parts: When replacement parts are required, be sure the service technician has used original Barco replacement parts or authorized replacement parts which have the same characteristics as the Barco original part. Unauthorized substitu- tions may result in degraded performance and reliability, fire, electric shock or other hazards. -
Page 7: Product Safety Labels
2.0 meters (SH image 1-1) above any surface upon which persons are assumed to stand or 1 meter (SW image 1-1) below or in lateral separation from any place where such persons are assumed to be. See image 1-1. R5906695 DP2K-E SERIES 19/06/2015... -
Page 8: Hd In Function Of The Lens Throw Ratio (Tr)
(RZ) in the theater must be established. This can be done by using physical barrier, like a red rope as illustrated in image 1-2. Image 1-2 HD in function of the lens Throw Ratio (TR) TR (Throw Ratio) The ratio of the distance to the screen (throw) to the screen width. R5906695 DP2K-E SERIES 19/06/2015... -
Page 9: Hazard Distance
1. Safety Hazard Distance Image 1-3 HD (in meter) in function of the Throw Ratio (TR) R5906695 DP2K-E SERIES 19/06/2015...
