KYMCO Agility 125 Service Manual page 136

12
. FRONT WHEEL/FRONT BRAKE/
FRONT SUSPENSION
Place the brake master cylinder on the
handlebar and install the holder with "up"
mark facing up. Be sure to align the punch
mark with the holder joint.
First tighten the upper bolt and then tighten
the lower bolt.
Torque: 3.0～4.0kgf-m
Install the brake fluid pipe with the attaching
bolt and two sealing washers.
Install the handlebar covers. ( 12-3)
Fill the brake reservoir with recommended
brake fluid to the upper limit and bleed air
according to the method stated in 12-10.
BRAKE CALIPER (FRONT)
Removal
Remove the brake caliper.
Place a clean container under the brake
caliper and disconnect the brake fluid pipe
from the caliper.
＊
Do not spill brake fluid on any coated
surfaces.
12-15
Bolts
Brake Caliper
Bolt
AGILITY 125
Punch Mark
"Up" Mark
Bleed Valve
Bleed Valve
