1.5 Magnet fitting

• Stick the magnet to the door frame opposite and below (20mm) to the cylinder fixing screw (M5 screw).
• Use the double sided sticker supplied.
Note: The magnet area on door frame should be clean and free from dust, peeling paint etc. Use alcohol if
required. Wait until completely dry prior to sticking.

1.6 Cylinder to unit assembly (optional)

Note: Follow those instructions only if the cylinder was dismantled from the door unit.
• Insert operating key into the external side of the cylinder and turn one full turn.
• Take the key out.
Note: Verify that the gear is not pressed in.
Page 6
Door frame
M5 Screw
Stick the magnet to door frame opposite
Magnet
and below (20mm) to the M5 screw
Gear not pressed in
ENTR™ User Manual
