5. Touchpad Reader operation

5.1 Operation

To turn the Touchpad Reader ON press [#] for 5 seconds. The reader will perform a self test followed by
series of beeps. Led blinks Green, Red, Blue.

5.2 Pairing Touchpad Reader

This procedure is done via the ENTR™ lock. See also Pairing Remote Control unit procedure.
1
Touch ENTR™ lock screen with palm
or fingers for 3 seconds to active
5
Touch the Touchpad Reader screen
with palm or fingers
Press [77] [#]
Blue LED blinking rapidly
• Hang the Touchpad Reader on the base plate.
• Tighten fixing screw.
ENTR™ User Manual
2
Press [Add]
Pairing OK
[OK] indication blinks once
2 short beeps emitted
Touchpad Reader added
3
Numeric buttons illuminated
Type [Pin code] [#]
Numeric buttons blinking
Pairing failed
[OK] indication blinks for 15 seconds
No beeps emitted
In wall reader: Green LED illuminated
and 2 beeps emitted
Start the process from stage 1
4
Press [1] to add Touchpad
Illuminated buttons turn off
[OK] indication blinks for 15 seconds
waiting for the Touchpad
Fixing screw
Page 17
