6.3 Initial configuration

1. Touch [#] for 3 seconds. The reader will perform self calibration followed by a series of beeps and blinking
LEDs. At the end of the calibration the screen will display:
2. Adjust Date & Time.
DEVICE
DATE/TIME

6.4 Pairing fingerprint reader

This procedure is done via the ENTR™ lock. See also Pairing Touchpad Reader procedure.
1
Touch ENTR™ lock screen with palm
or fingers for 3 seconds to active
5
Touch Fingerprint Reader screen
2 short beeps emitted
Press [OK] for YES or [ ] to cancel
*
MATCH LOCK?
*-NO OK-YES
Note: At the end of the initial matching
process a short warning will be displayed.
ENTR™ User Manual
--/--/--
DD/MM/YY
Enter Date
2
Press [Add]
Pairing OK
[OK] indication blinks once
2 short beeps emitted
Fingerprint Reader added
LOCK
MATCHED
SUCCESS
CALIBRATE
--/--
12
[OK]
11 1
10 2
9 3
8 4
7 5
6
hh:mm
Enter Time
3
Numeric buttons illuminated
Type [Pin code] [#]
Numeric buttons blinking
Pairing failed
1 long beep emitted
Red LED illuminated for 2 seconds
FAILED
MATCH
WARNING
NO USERS
15/03/15
12
[OK]
11 1
10 2
9 3
8 4
7 5
6
11:00
4
Press [1] to add the reader
Illuminated buttons turn off
[OK] indication blinks for 15
seconds waiting for the reader
Page 21
