5. Touchpad Reader Operation

5.1 Operation

To turn the Touchpad Reader ON press [#] for 5 seconds. The reader will perform a
self-test, followed by series of beeps. LED blinks green, red, and Blue.

5.2 Pairing Touchpad Reader

This procedure is done via the ENTR® lock. See also: Pairing Remote Control.
1
Touch ENTR® lock screen with palm
or fingers for 3 seconds to active.
4
Press [1] to add Touchpad.
Illuminated buttons turn off.
[OK] indication blinks for 15 seconds,
waiting for the Touchpad.
22
2
Press [Add]
5
Touch the Touchpad Reader screen
with palm or fingers.
Press [77] [#]
Blue LED blinking rapidly.
3
Numeric buttons illuminated.
Type [PIN Code] [#]
Numeric buttons blink.
