AVG-HD402PR
The AVG-HD402PR uses HDBaseT technology
to deliver HDMI signal with a maximum
transmission distance up to 60 meters with
CAT5e/CAT6 cable.
Features
Supports Full HD: Delivers resolutions
including 800x600@60Hz,
1024x768@Hz,1280x720@60Hz,
1280x1024@60Hz, 1366x768@60Hz,
1600x1200@60Hz,1920x1080@60Hz,
1920x1200@60Hz, 3D, 4K×2K
Max transmission distance is up to 60
meters over single CAT5e/CAT6 cable.
High Bandwidth: 10.2Gps.
HDTV Compatible, HDMI 1.4 and
HDCP compliant.
Supports PoC & CEC.
Connect with a display to transmit
EDID and HPD signals constantly
by using a CAT5e cable.
Uses HDBaseT technology.
Bi-directional RS232/IR control.
LED indicators show working status.
Wall/table-mountable aluminium
enclosure, PT case design.
Advertisement
Table of Contents
Related Manuals for AVGear AVG-HD402PR
Summary of Contents for AVGear AVG-HD402PR
- Page 1 HDCP compliant. Supports PoC & CEC. Connect with a display to transmit EDID and HPD signals constantly The AVG-HD402PR uses HDBaseT technology by using a CAT5e cable. to deliver HDMI signal with a maximum Uses HDBaseT technology. transmission distance up to 60 meters with Bi-directional RS232/IR control.
- Page 2 AVG-HD402PR PLEASE READ THIS PRODUCT MANUAL CAREFULLY BEFORE USING THIS PRODUCT. This manual is only for operation instruction only, and not to be used in a maintenance capacity. The functions described in this version are current as at March 2015. Any changes of functions and operational parameters will be updated in future manual versions.
- Page 3 AVG-HD402PR SAFETY OPERATION GUIDE In order to guarantee the reliable operation of the equipment and safety of the user, please abide by the following procedures in installation, use and maintenance: 1. The system must be earthed properly. Please do not use two blade plugs and ensure the AC power supply ranges from 100v to 240v and from 50Hz to 60Hz.
-
Page 4: Table Of Contents
Introduction ......................1 Introduction to the AVG-HD402PR ............... 1.1 Features ....................... 1.2 What’s in the Box ..……………………………………………………………………2 Product Appearance of the AVG-HD402PR ............3 Appearance of AVG-HD402PR ..............3.1 Appearance of AVG-HD402T ................. 3.2 System Connection ....................4 System Applications ..................4.1 Usage Precautions .................. -
Page 5: Introduction
AVG-HD402PR 1. Introduction 1.1. Introduction to the AVG-HD402PR The AVG-HD402PR is an HDMI/IR/RS232 twisted pair including a transmitter (AVG- HD402T) and receiver (AVG-HD402PR). The AVG-HD402PR uses HDBaseT technology to deliver HDMI signal, max transmission distance up to 60 meters with CAT5e/CAT6 cable. - Page 6 AVG-HD402PR 2. Package List 1 x AVG-HD402PR 1 x AVG-HD402T 4 x Mounting brackets 8 x Plastic cushions 2 x RS232 cables 8 x Screws 2 x Power adapters (DC 24V) 1 x User manual Note: Please confirm if the product and the accessories are all included, if not,...
-
Page 7: Product Appearance Of The Avg-Hd402Pr
AVG-HD402PR 3. Product Appearance of the AVG-HD402PR 3.1. Appearance of AVG-HD402PR Name Description Working status indicator, blinks green when the device is ① operational, turns off when the device stops working. Twisted Pair link status indicator, illuminates green when the ②... -
Page 8: Appearance Of Avg-Hd402T
HDCP and is operational; blinks green when the connected device does not support HDCP. POWER ④ Illuminates red when power is on. Connect to the HDBT IN port of a AVG-HD402PR with a CATx ⑤ HDBT OUT cable. ⑥... -
Page 9: System Connection
AVG-HD402PR 4. System Connection 4.1. System Applications Reliable performance for control and transmission makes the AVG-HD402PR ideal in the IT computer space, signal monitoring, big screen displays, conference systems, television broadcast, education, banking and security institutions etc. 4.2. Usage Precautions 1. -
Page 10: Connection Procedure
Connect a HDMI display (such as HDTV) to HDMI OUT port of AVG- HD402PR with HDMI cable. Step 4. Both AVG-HD402T and AVG-HD402PR have IR IN and OUT. When one end is used as an IR receiver, the other end will be used as an IR transmitter. -
Page 11: Twisted Pair Connection
AVG-HD402PR 4.5. Twisted Pair Connection The twisted pair used in this extender MUST be a straight-through cable. The connectors can be T568A or T568B, but both sides must be the same. TIA/EIA T568A Cable Color Cable Color orange white green white... -
Page 12: Associated Products
AVG-HD402PR 4.6. Associated Products AVG-HD402PR usually works together with other devices to extend the transmission distance of HDMI/IR/RS232 signal. Here are the most commonly associated products. Description: 1) SC51T (mini scaler switcher) Bi-directional IR & RS232 control. Compliant with HDCP. - Page 13 AVG-HD402PR Bridge connection function. User can switch the MA1 to be 1x40Watt@8Ω by bridge connection. 48V phantom power to support condenser microphone. MIC port can support balance/unbalance signal, suppress the external noise effectively.
-
Page 14: Specifications
AVG-HD402PR 5. Specifications Model AVG-HD402T AVG-HD402PR Spec Input Input Signal 1 HDMI,1 IR & 1 RS232 1 IR, 1 RJ-45 & 1 RS232 HDMI female, 3.5mm 3.5mm mini jack, RJ- Input Connector mini jack, 3-pin captive 45, 3-pin captive screw connector... -
Page 15: Panel Drawing
AVG-HD402PR 6. Panel Drawing... -
Page 16: Troubleshooting & Maintenance
AVG-HD402PR 7. Troubleshooting & Maintenance Problems Causes Solutions Incorrect setting on Check the display’s Output images in the display setting display contains Poor cable quality Try another high ghosting q u a l i t y connection cable Check with oscilloscope...
