AVG-HD300
AVG-HD300 is an HDMI/IR/RS232 twisted pair
including a transmitter (AVG-HD300T) and
receiver (AVG-HD300R).
Features
Supports Full HD: Delivers
resolutions including
800x600@60Hz, 1024x768@Hz,
1280x720@60Hz,
1280x1024@60Hz,
1366x768@60Hz,
1600x1200@60Hz,
1920x1080@60Hz,
1920x1200@60Hz, 3D, 4K×2K
Max transmission distance is up
to 60 meters over single
CAT5e/CAT6 cable.
High Bandwidth: 10.2Gps.
HDTV Compatible, HDMI 1.4 and
HDCP compliant.
Supports PoC & CEC.
HDBaseT technology.
Advertisement
Table of Contents
Related Manuals for AVGear AVG-HD300
Summary of Contents for AVGear AVG-HD300
- Page 1 1920x1200@60Hz, 3D, 4K×2K Max transmission distance is up to 60 meters over single CAT5e/CAT6 cable. High Bandwidth: 10.2Gps. AVG-HD300 is an HDMI/IR/RS232 twisted pair HDTV Compatible, HDMI 1.4 and including a transmitter (AVG-HD300T) and HDCP compliant. receiver (AVG-HD300R). Supports PoC & CEC.
- Page 2 AVG-HD300 PLEASE READ THIS PRODUCT MANUAL CAREFULLY BEFORE USING THIS PRODUCT. This manual is only for operation instruction only, and not to be used in a maintenance capacity. The functions described in this version are current as at March 2015. Any changes of functions and operational parameters will be updated in future manual versions.
- Page 3 AVG-HD300 SAFETY OPERATION GUIDE In order to guarantee the reliable operation of the equipment and safety of the user, please abide by the following procedures in installation, use and maintenance: 1. The system must be earthed properly. Please do not use two blade plugs and ensure the alternating power supply ranges from 100v to 240v and from 50Hz to 60Hz.
-
Page 4: Table Of Contents
AVG-HD300 TABLE OF CONTENTS Introduction ......................Introduction to AVG-HD300 ................Features ....................... 1.2 What’s in the Box ..................... 2 Introduction of Product Appearance ..............Appearance of AVG-HD300-T ..............Appearance of AVG-HD300-R..............3.2 System Connection ....................4 Usage Precautions ..................4.1 System Diagram ................... -
Page 5: Introduction
HD300 uses HDBaseT technology to deliver HDMI signals, max transmission distance up to 60 meters with CAT5e/CAT6 cable. CEC, bi-directional RS232&IR control, and PoC (Power over Cable) are supported by the AVG-HD300. 1.2 Features Supports Full HD: Delivers resolutions including 800x600@60Hz,... -
Page 6: Appearance Of Avg-Hd300T
AVG-HD300 3. Product Appearance 3.1 Appearance of AVG-HD300T ON: Working status indicator, blink green when the device works fine, turn off when the device stops working. LINK: Twisted Pair link status indicator, illuminate green when the connection is successful. IN: HDCP compliance indicator, illuminate green when the connected device supports HDCP and work normally;... -
Page 7: Appearance Of Avg-Hd300R
AVG-HD300 3.2 Appearance of AVG-HD300R ON: Working status indicator, blink green when the device works fine, turn off when the device stops working. LINK: Twisted Pair link status indicator, illuminate green when the connection is successful. IN: HDCP compliance indicator, illuminate green when the connected device supports HDCP and work normally;... -
Page 8: System Connection
Step1. Connect HDMI source (such as Blue-ray DVD) to HDMI IN port of AVG-HD300T with HDMI cable. Step2. Connect HDBT OUT port of AVG-HD300-T to HDBT IN port of AVG- HD300R through a CAT5e/CAT6 cable. Step3. Connect a HDMI displayer (such as HDTV) to HDMI OUT port of AVG-HD300R with HDMI cable. -
Page 9: Application
AVG-HD300 4.4 Application AVG-HD300 has ideal and suited for use in the IT realm, monitoring, large screen displays, meeting rooms, education, bank & security institutions etc. 4.5 Twisted Pair Cable Connection TIA/EIA T568A TIA/EIA T568B Cable Cable color color green... -
Page 10: Associated Products
AVG-HD300 5. Associated Products AVG-HD300 usually works together with other devices to extend the transmission distance of HDMI/IR/RS232 signal. Here are the most common products used in conjunction with the AVG-HD300. Description: 1) DSS52T (mini scaler switcher) Bi-directional IR & RS232 control. -
Page 11: Specification
AVG-HD300 6. Specification Model AVG-HD300T AVG-HD300R Spec Input Input Signal 1 HDMI,1 IR & 1 RS232 1 IR, 1 RJ-45 & 1 RS232 Input Connector HDMI female, 3.5mm mini jack 3.5mm mini jack, RJ-45 Video Signal HDMI1.4 HDMI1.4 Digital audio, transmits through... - Page 12 AVG-HD300 7. Panel Diagram...
- Page 13 AVG-HD300 8. Troubleshooting & Maintenance Problems Causes Solutions Output images in display Incorrect setting on the Check the display’s setting ghosting display Poor Quality Cable Replace Cable No output image when No signal at the input / output Check with oscilloscope or...
