- Page 1 UHD70LA 18Gbps HDMI Extender with Audio de-embedded & Scaling UHD70LA VER 1.0...
- Page 2 UHD70LA PLEASE READ THIS PRODUCT MANUAL CAREFULLY BEFORE USING THIS PRODUCT. This manual is only for operational instruction only, and is not to be used in a maintenance capacity. The functions described in this version are current as at June 2022. Any changes of functions and operational parameters will be updated in future manual versions.
- Page 3 UHD70LA SAFETY OPERATION GUIDE In order to guarantee the reliable operation of the equipment and safety of the user, please abide by the following procedures during installation, use and maintenance: The system must be earthed properly. Please do not use two blade plugs and ensure the AC power supply ranges from 100v to 240v and from 50Hz to 60Hz.
-
Page 4: Table Of Contents
UHD70LA TABLE OF CONTENTS 1. Introduction......................... 1 2. Features..........................1 3. Package Contents......................2 4. Specifications........................2 5. Operation Controls and Functions.................4 5.1 Transmitter Panel......................4 5.2 Receiver Panel....................... 5 5.3 IR Pin Definition......................7 6. Application Example......................8... -
Page 5: Introduction
UHD70LA 1. Introduction UHD70LA is an 18Gbps HDMI Extender can extend HDMI HD signal and IR control signal to a distance up to 230ft / 70m via a single CAT6/6a cable, which can achieve zero-delay, uncompressed long-distance transmission between the transmitter and receiver. Video resolution is up to 4K2K@60Hz. -
Page 6: Package Contents
UHD70LA 3. Package Contents 1 x UHD70LA-T (Transmitter) 1 x UHD70LA-R (Receiver) 1 x IR Blaster Cable (1.5 meters) 1 x IR Wideband Receiver cable (1.5 meters) 4 x Mounting Brackets 8 x Screws (KM3*4) 1 x 12V/1A Locking Power Adapter 1x User Manual 4. - Page 7 UHD70LA Connection Input: 1×Source [Type A, 19-pin female] Output: 1×HDMI Loop [RJ45] 1×Link To RX [RJ45] Transmitter Control: 1×Service [Micro-USB jack] 1×IR In [3.5mm Stereo Mini-jack] 1×IR Out [3.5mm Stereo Mini-jack] Input: 1×Link To TX [RJ45] Output: 1×To Display [Type A, 19-pin female] 1×Toslink...
-
Page 8: Operation Controls And Functions
UHD70LA 5. Operation Controls and Functions 5.1 Transmitter Panel Name Function Description Firmware update port. Service HDMI signal loop output port. Connect to HDMI display HDMI Loop devices with HDMI cable. HDMI signal input port. Connect to HDMI source device with Source In HDMI cable. -
Page 9: Receiver Panel
UHD70LA Name Function Description DC 12V/1A power input port. Note that the extender supports PoC function, it means that either DC 12V Transmitter or Receiver is connected to 12V/1A power supply, the other doesn’t need power supply. Use the DIP switch to set EDID. (Switching to the upper end indicates 1;... - Page 10 UHD70LA Name Function Description ▪ Illuminating: Transmitter and Receiver are in good Link Signal connection status. Indicator ▪ Flashing: Transmitter and Receiver are in poor connection (Green) status. ▪ Dark: Transmitter and Receiver are not connected. ▪ Illuminating: HDMI signal with HDCP.
-
Page 11: Ir Pin Definition
UHD70LA 5.3 IR Pin Definition IR Receiver and Blaster pin’s definition is as below: Note: ▪ When the angle between the IR receiver and the remote control is ± 45 °, the transmission distance is 0-5 meters; ▪ When the angle between the IR receiver and the remote control is ± 90 °, the... -
Page 12: Application Example
UHD70LA 6. Application Example...
