  • Page 1 GV-IPCam H.264 Hardware Manual Box Camera Ultra Box Camera Arctic Box Camera Target Box Camera Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. ICH264TG2V10-B...
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.

  • Page 3: Table Of Contents

    1.2 Features ...................6 1.2.1 Wide Dynamic Range Pro..........9 1.3 Overview ................10 1.3.1 GV-BX120D / 130D Series / 140DW / 220D Series / 320D Series / 520D .............10 1.3.2 GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 2600 / 3400 Series / 5300 Series / 12201 ..................12...
  • Page 4 Chapter 2 IR Arctic Box Camera ........24 2.1 Packing List ................26 2.2 Features .................28 2.3 Overview ................30 2.3.1 GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E / 3400-E / 5300-E ............30 2.3.2 GV-BX2510-E / 5310-E..........31 2.4 Installation ................32 2.5 Connecting the Camera............38...
  • Page 5 2.7 Loading Factory Default............46 Chapter 3 Ultra Box Camera ..........47 3.1 Packing List ................48 3.2 Features .................49 3.3 Overview .................50 3.4 Installation ................51 3.5 Connecting the Camera............53 3.6 Loading Factory Default ............54 Chapter 4 Target Box Camera ........55 4.1 Packing List ................55 4.2 Features .................56 4.3 Overview ................57 4.4 Installation ................58...

  • Page 6: Options

    Options Optional devices can expand your camera’s capabilities and versatility. Contact your dealer for more information. Device Description The power adapter is available for all Box Camera, Ultra Box Camera, and Target Box Camera. Contact Power Adapter your sales representative for the countries and areas supported.
  • Page 7 Device Description The GV-WiFi Adapter is a plug-and-play device designed to connect GV-BX1200 Series / 1300 series / 1500 series / 2400 series / 2500 series / 3400 series / 5300 series and GV-MFD1501 series / GV-WiFi Adapter 2401 series / 2501 series / 3401 series / 5301 series to wireless network.

  • Page 8: Note For Installing Camera Outdoor

    Note for Installing Camera Outdoor When installing the IR Arctic Box Camera outdoor, be sure that: The camera is set up above the junction box to prevent water from entering the camera along the cables. Any PoE, power, audio and I/O cables are waterproofed using waterproof silicon rubber or the like.

  • Page 9: Note For Usb Storage And Wifi Adapter

    Note for USB Storage and WiFi Adapter Mind the following limitations and requirements for using USB storage and GV-WiFi Adapter: The USB hard drive must be of 2.5’’ or 3.5’’, version 2.0 or above. The USB hard drive’s storage capacity must not exceed 2TB. USB flash drives and USB hubs are not supported.

  • Page 11: Chapter 1 Box Camera

    The Box Camera models are detailed below: Box Camera Model No. Specifications Description Auto Iris, f:2.8 ~ 12 1.3 MP, H.264, GV-BX120D mm, F/1.4, 1/3” CS Low Lux, D/N Lens Varifocal Lens Auto Iris, f: 2.8 ~ 12 1.3 MP, H.264, mm, F/1.4, 1/3’’...
  • Page 12 Model No. Specifications Description Auto Iris, f: 2.8 ~ 12 Varifocal 2 MP, H.264, GV-BX220D-3 mm, F/1.4, 1/3’’ CS Lens Lens Auto Iris, f:3.1 ~ 8 mm, F/1.2, 1/3” CS GV-BX320D-0 Lens 3 MP, H.264, Auto Iris, f: 2.8 ~ 6 Varifocal GV-BX320D-1 mm, F/1.3, 1/3’’...
  • Page 13 Box Camera Model No. Specifications Description 1.3 MP, H.264, GV-BX1200-2F Low Lux, D/N 1.3 MP, H.264, GV-BX1300-2F 1.3 MP, H.264, GV-BX1500-2F Super Low Fixed Iris, f: 12 mm, Lux, D/N Fixed Lens F/1.6, 1/2.5’’ CS 2 MP, H.264, Lens GV-BX2400-2F D/N, WDR Pro 2 MP, H.264, GV-BX2500-2F...
  • Page 14 Manual Iris, f: 4.5 ~ 5 MP, H.264, 10 mm, F/1.6, 1/2’’ GV-BX5300-6V CS Lens 1.3 MP, H.264, GV-BX1500-8F Super Low Lux, D/N 2 MP, H.264, GV-BX2500-8F Super Low Fixed Iris, f: 2.8 mm, Lux, D/N Fixed Lens F/1.8, 1/2.5’’ CS Lens 3 MP, H.264, GV-BX3400-8F...

  • Page 15: Packing List

    Box Camera 1.1 Packing List  Box Camera  Terminal Block  Fixed Focal or Varifocal Megapixel Lens  Six Lens Rings  One 0.125 mm Lens Ring (for GV-BX140DW only)  Video Out Wire  Camera Holder  Holder Screw x 2 ...

  • Page 16: Features

    1.2 Features  Image sensor Camera Model Image Sensor GV-BX120D 1/3’’ progressive scan low lux CMOS GV-BX1200 Series GV-BX130D Series GV-BX1300 Series GV-BX220D Series 1/2.5’’ progressive scan CMOS GV-BX320D Series GV-BX520D GV-BX5300 Series GV-BX140DW 1/3’’ progressive scan CMOS GV-BX1500 Series 1/3’’...
  • Page 17 Box Camera  Frame Rate Camera Model Frame Rate GV-BX120D GV-BX130D Series GV-BX1200 Series Up to 30 fps at 1280 x 1024 GV-BX1300 Series GV-BX1500 Series GV-BX140DW Up to 30 fps at 1280 x 720 GV-BX220D Series GV-BX2400 Series Up to 30 fps at 1920 x 1080...
  • Page 18  Recording assigned by GV-Edge Recording Manager (Windows & Mac) for Box Camera using firmware V3.0 or later  Mini USB slot for WiFi Adapter or a USB hard drive (for GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 2600 / 3400 Series / 5300 Series only) ...

  • Page 19: Wide Dynamic Range Pro

    Box Camera 1.2.1 Wide Dynamic Range Pro Objects may appear as silhouettes when they are backed with intense lights. The Wide Dynamic Range Pro (WDR Pro) is designed to solve this problem using a WDR sensor. In GV-BX140DW, GV-BX2400 Series, GV- BX2600 and GV-BX3400 Series, the WDR sensor is able to process the image and show details in bright and dark areas at the same time.

  • Page 20: Overview

    12 13 Figure 1-1 Note: 1. The Auto Iris connector (No. 7) is only functional in GV-BX120D, GV-BX130D-0, GV-BX220D and GV-BX320D. 2. The Light Sensor (No.11) is only available in GV-BX140DW. Keep the Light Sensor unobscured for accurate light detection.
  • Page 21 Box Camera Name Description Audio Out Connects a speaker for audio output. Audio In Connects a microphone for audio input. I/O Terminal For details, see 1.6 I/O Terminal Block. Block Indicates the power is supplied. For detail, see Power LED the table below.

  • Page 22: Gv-Bx1200 Series / 1300 Series / 1500 Series / 2400

    1.3.2 GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 2600 / 3400 Series / 5300 Series / 12201 Figure 1-2-1 Figure 1-2-2: GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 2600 / 3400 Series / 5300 Series Figure 1-2-1: GV-BX12201...
  • Page 23 Box Camera Note: The Auto Iris Connector (No. 8) is only functional for varifocal models of GV-BX1200 / 1300 / 1500 / 2400 / 2500 / 2600 / 3400. The Iris Screw (No. 12) is only available in GV-BX5300-6V. The Zoom Screw (No. 13) is only available for varifocal models of GV-BX1200 / 1300 / 1500 / 2400 / 2500 / 2600 / 3400 / 5300 / 12201.
  • Page 24 Restores the camera to factory default. For Default details, see 1.7 Loading Factory Default. Iris Screw Adjusts the iris of the camera. Zoom Screw Adjusts the zoom of the camera. Microphone Records the sounds. Focus Screw Adjusts the focus of the camera. Turns on when the unit is ready for use.

  • Page 25: Connecting The Camera

    1.4 Connecting the Camera The Box Camera is designed for indoor use. Please make sure the installing site is shielded from rain and moisture. 1.4.1 GV-BX120D / 130D Series / 140DW / 220D Series / 320D Series / 520D Figure 1-3 If you are using an auto iris model, plug the iris control cable to the Auto Iris Connector on the camera.
  • Page 26 Optionally connect to input / output devices or an infrared illuminator. For details, see 1.5.2 Infrared Illuminator and 1.6 I/O Terminal Block. Connect power using one of the following methods:  plugging the power adapter to the power port.  using the Power over Ethernet (PoE) function and the power will be provided over the network cable.

  • Page 27: Gv-Bx1200 Series / 1300 Series / 1500 Series / 2400

    Box Camera 1.4.2 GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 2600 / 3400 Series / 5300 Series / 12201 Figure 1-4 If you are using an auto iris model, plug the iris control cable to the Auto Iris Connector on the camera.
  • Page 28 Optionally connect a monitor using a Video Out wire. Enable this function by selecting your signal format at the TV Out field on the Web interface. See 4.1.1 Video Settings, GV-IPCam H.264 Firmware Manual. Optionally connect to input / output devices or an infrared illuminator. For details, see 1.5.2 Infrared Illuminator and 1.6 I/O Terminal Block.

  • Page 29: Accessory Installation

    Box Camera 1.5 Accessory Installation 1.5.1 C-Mount Lenses If you use a C-mount lens, it requires a certain distance from the camera’s imaging chip to focus the lens. Mount the supplied C-mount lens adapter / lens ring to the camera, and then secure the lens onto the camera body. Three types of C-mount lens rings are provided for Box Camera: ...

  • Page 30: Infrared Illuminators (Optional)

    1.5.2 Infrared Illuminators (Optional) If you use an infrared (IR) illuminator with I/O function, follow the steps below to install it. Connect the infrared illuminator to the terminal block on the camera. See 1.6 The I/O Terminal Block. Access the Web interface of the camera. Select Video and Motion, select Video Settings, select Streaming 1 and set the IR Check Function setting to Trigger by Input.

  • Page 31: I/O Terminal Block

    Box Camera 1.6 I/O Terminal Block The terminal block, located on the back panel of the Box Camera, provides the interface to one input and one output devices. The I/O terminal block can be used for applications such as motion detection, event alerts via E- Mail and FTP, and center monitoring through Center V2 and VSM.

  • Page 32: Connecting To Gv-Relay V2 (Optional)

    1.6.2 Connecting to GV-Relay V2 (Optional) The Box Camera can only drive a maximum load of 200mA 5V DC. To expand the maximum voltage load to 10A 250V AC, 10A 125V AC or 5A 100V DC, connect the camera to a GV-Relay V2 module (optional product). Refer to the figure and table below.

  • Page 33: Loading Factory Default

    Box Camera 1.7 Loading Factory Default Keep the power and network cables connected to the camera. Use a pin to press and hold the default button on the back panel of the camera. Default button Figure 1-8 Release the default button when the status LED blinks. This shall take about 8 seconds.

  • Page 34: Chapter 2 Ir Arctic Box Camera

    IR Arctic Box Camera Model No. Specifications Description Auto Iris, f: 2.8 ~ 12 1.3 MP, H.264, GV-BX120D-E mm, F/1.4, 1/3” CS Low Lux, D/N Lens Auto Iris, f: 2.8 ~ 6 mm, GV-BX220D-E 2 MP, H.264, D/N F/1.3, 1/3’’...
  • Page 35 IR Arctic Box Camera Model No. Specifications Description P-Iris, f: 3.7 ~ 9 mm, 2 MP, H.264, GV-BX2510-E F/1.2, 1/2’’, ø 14 Super Low Lux, mm mount Motorized Varifocal Lens P-Iris, f: 4.5 ~ 9 mm, 5 MP, H.264 GV-BX5310-E F/1.2, 1/2’’, ø...

  • Page 36: Packing List

    2.1 Packing List For GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E / 3400-E / 5300-E  IR Arctic Box Camera  Screw Anchor x 4  Screw x 4  Washer x 4  4 mm Torx Wrench ...
  • Page 37 IR Arctic Box Camera For GV-BX2510-E / 5310-E  IR Arctic Box Camera  Screw Anchor x 4  Screw x 4  Washer x 4  5 mm Torx Wrench  Silica Gel Bag  Adhesive Tape for Silica Gel Bag ...

  • Page 38: Features

    2.2 Features  Image sensor Camera Model Image Sensor GV-BX120D-E 1/3" progressive scan low lux CMOS GV-BX1500-E 1/3" progressive scan super low lux CMOS GV-BX220D-E GV-BX320D-E 1/3.2" progressive scan CMOS GV-BX520D-E GV-BX5300-E GV-BX2510-E 1/2.8” progressive scan super low lux CMOS...
  • Page 39 IR Arctic Box Camera  P-Iris for auto iris adjustment (for GV-BX2510-E / 5310-E)  Vandal resistance (IK10 for metal casing)  Built-in heater and fan  Support for TV-out  Micro SD card slot (SD/SDHC) for local storage (for GV-BX2510-E / 5310-E) ...

  • Page 40: Overview

    2.3 Overview 2.3.1 GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E / 3400-E / 5300-E Figure 2-1 Note: The Iris Screw (No. 7) is only available in GV-BX520D-E and GV- BX5300-E. Name Description Silica gel bag Desiccant that keeps the camera housing dry.

  • Page 41: Gv-Bx2510-E / 5310-E

    IR Arctic Box Camera 2.3.2 GV-BX2510-E / 5310-E Figure 2-2 Name Description Silica gel bag Desiccant that keeps the camera housing dry. Memory Card Inserts a micro SD card (SD/SDHC, version Slot 2.0, Class 10) to store recording data. Turns on when the camera is supplied with Power LED power.

  • Page 42: Installation

    2.4 Installation The IR Arctic Box Camera is designed for outdoor use. Follow the steps below to install your camera. Mark the installation site and drill four holes for screw anchors. Insert the supplied screw anchors. Secure the camera to the wall using the supplied washers and screws. Figure 2-3 Connect the camera with wires and cables.
  • Page 43 Pan Adjustment Figure 2-6 For GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E / 3400-E / 5300-E , adjust for image clarity based on the live view. A. Unscrew the cover with the supplied 4 mm torx wrench.
  • Page 44 B. Hold and unplug the connector. Figure 2-8 IMPORTANT: Unscrew and remove the cover carefully. Pulling the cover off may cause damages to the inner wiring of the camera. C. Adjust the focus, zoom and iris screws. For a more precise focus, use GV-IP Device Utility.
  • Page 45 IR Arctic Box Camera D. Replace the silica gel bag. Paste the sticker to the silica gel bag. Press the sticker several times onto the camera cover to make sure it adheres properly. Figure 2-10 E. Follow steps 7B and 7A to plug the connector back and close the camera cover.
  • Page 46 B. Insert a memory card to the card slot. Memory card slot Figure 2-12 C. Replace the silica gel bag. Paste the sticker to the silica gel bag. Press the silica gel bag several times onto the camera cover to make sure it adheres properly.
  • Page 47 IR Arctic Box Camera IMPORTANT: The gel bag loses its effectiveness when the dry camera is opened. To prevent the lens from fogging up, replace the silica gel bag every time you open the camera, and conceal the silica gel bag in the camera within 2 minutes of exposing to open air.

  • Page 48: Connecting The Camera

    2.5 Connecting the Camera 2.5.1 GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E / 3400-E / 5300-E Figure 2-14 Wire Definition RJ-45 Black BNC TV out Green RCA Audio Out Pink RCA Audio In...
  • Page 49 IR Arctic Box Camera Optionally connect a speaker (green) and an external microphone (pink). Optionally connect a monitor using a Video Out wire. Enable this function by selecting your signal format at the TV Out field on the Web interface. See 4.1.1 Video Settings, GV-IPCam H.264 Firmware Manual.

  • Page 50: Gv-Bx2510-E / 5310-E

    2.5.2 GV-BX2510-E / 5310-E Figure 2-16 Wire Definition Green RCA Audio Out Pink RCA Audio In Brown wire Digital Output Yellow wire Digital Input White wire Terminal Block DC 48V TV Out RJ-45 Ethernet/PoE 1. Optionally connect the audio out (green), audio in (pink), digital output (brown), digital input (yellow), and GND.
  • Page 51 IR Arctic Box Camera 3. Supply the camera with power and network access using one of the following methods:  Use a GV-PA482 Power over Ethernet adapter to connect the camera to power and network as illustrated below. GV-PA482 PoE adapter is an optional accessory.
  • Page 52 4. You are ready to access the live view.

  • Page 53: Notice For Using The Ir Arctic Box Camera

    IR Arctic Box Camera 2.6 Notice for Using the IR Arctic Box Camera For GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E / 3400-E / 5300-E , make sure that you:  enable IR LED function on the Web interface after loading the default settings.

  • Page 54: Enabling Ir Led After Loading Default

    2.6.1 Enabling IR LED after Loading Default Each GV-IR Arctic Box Camera is equipped with 4 IR LEDs to provide infrared illumination at night. The factory-loaded setting for the IR LED function is enabled . If you have restored the camera to default settings, please follow the steps below to enable the IR LED function.

  • Page 55: Disabling Status Led Under Low Light Conditions

    IR Arctic Box Camera 2.6.2 Disabling Status LED under Low Light Conditions If you have a green light spot on the live view, this is likely due to insufficient light at the installation site, which causes the status LED to reflect on the camera cover.

  • Page 56: Loading Factory Default

    2.7 Loading Factory Default Note that only GV-BX2510-E and GV-BX5310-E are equipped with a default button. Keep the power and network cables (or PoE) connected to the camera. Press and hold the default button. Status LED Default button Figure 2-19 Release the default button when the status LED blinks.

  • Page 57: Chapter 3 Ultra Box Camera

    Ultra Box Camera Chapter 3 Ultra Box Camera The Ultra Box Camera is a series of light-weighted cameras designed for indoor usage. Equipped with IR-cut filter and built-in IR LEDs, the Ultra Box Camera provides excellent image quality. The camera supports PoE and can be installed intuitively.

  • Page 58: Packing List

    3.1 Packing List  Ultra Box Camera  Supporting rack  Screw x 3  Screw anchor x 3  Power Adapter  GV-IPCAM H.264 Software DVD  GV-NVR Software DVD  Warranty Card Note: The power adapter can be excluded upon request.

  • Page 59: Features

    Ultra Box Camera 3.2 Features  1/2.5’’ progressive scan CMOS  Dual streams from H.264 or MJPEG  Frame rate Camera Model Frame Rate GV-UBX1301 Series Up to 30 fps at 1280 x 1024 GV-UBX2301 Series Up to 30 fps at 1920 x 1080 GV-UBX3301 Series Up to 20 fps at 2048 x 1536 ...

  • Page 60: Overview

    3.3 Overview Figure 3-1 Name Description Audio Out Connects a speaker for audio output. Resets the camera to factory default. Default For details, see 3.6 Loading Factory Default. LAN / PoE Connects to a 10/100 Ethernet or PoE. Microphone Records sounds. Inserts a micro SD card (SD/SDHC, Memory Card Slot version 2.0 only, Class 10) to store...

  • Page 61: Installation

    Ultra Box Camera 3.4 Installation You can stand the Ultra Box Camera on a plain surface or install it to wall and ceiling. Follow the steps below to install, connect and adjust your Ultra Box Camera. To install the device on the wall/ceiling, put the supporting rack on the desired location and make marks for screw anchors.
  • Page 62 Connect the network and power cables to the camera. See 3.5 Connecting the Camera. Access the live view. See 2.1 Accessing the Live View, GV-IPCam H.264 Firmware Manual. Adjust the angle of the camera based on live view and fasten the indicated screw.

  • Page 63: Connecting The Camera

    Ultra Box Camera 3.5 Connecting the Camera Figure 3-5 Connect power using one of the following methods:  Plug the power adapter to the 5V terminal block. The power adapter is an optional device. For detail, see Options in the manual.

  • Page 64: Loading Factory Default

    3.6 Loading Factory Default Keep the power and network cables connected to the camera. Use a pin to press and hold the default button on the back panel of the camera. Default button Figure 3-6 Release the default button when the status LED blinks. This shall take about 8 seconds.

  • Page 65: Chapter 4 Target Box Camera

    Target Box Camera Chapter 4 Target Box Camera The Target Box Camera (GV-EBX) is a series of light-weighted cameras designed for indoor usage. Equipped with IR­cut filter and built­in IR LEDs, the camera is an entry-level surveillance solution with all the essential features and excellent image quality.

  • Page 66: Features

    4.2 Features  1/3” progressive scan low lux CMOS for GV-EBX1100 Series  Dual streams from H.264 or MJPEG Up to 30 fps at 1280 x 1024 for GV-EBX1100 Series  Intelligent IR  Day and night function (with removable IR-cut filter) ...

  • Page 67: Overview

    Target Box Camera 4.3 Overview Figure 4-1 Name Descri esets the came ra to factory default. For efault details, see 4.6 Loading Factory Default. LAN / PoE Connects to a 10/100 Ethernet or PoE. Microphone Records sounds. DC 12V Term inal Connects to powe Block...

  • Page 68: Installation

    4.4 Installation You can stand the Target Box Camera on a plain surface or install it to wall and ceiling. Follow the steps below to install, connect and adjust your Target Box Camera. To install the device on the wall/ceiling, put the supporting rack on the desired location and make marks for screw anchors.
  • Page 69 Target Box Camera Connect the network and power cables to the camera. See 4.5 Connecting the Camera. Access the live view. See 2.1 Accessing the Live View, GV-IPCam H.264 Firmware Manual. Adjust the angle of the camera based on live view and fasten the indicated screw.

  • Page 70: Connecting The Camera

    4.5 Connecting the Camera Figure 4-5 Connect power using one of the following methods:  Plug the power adapter to the 12V terminal block. The power adapter is an optional device. For detail, see Options in the manual.  Use the Power over Ethernet (PoE) function and the power will be provided over the network cable.

  • Page 71: Loading Factory Default

    Target Box Camera 4.6 Loading Factory Default Keep the power and network cables connected to the camera. Use a pin to press and hold the default button on the back panel of the camera. Default button Figure 4-6 Release the default button when the status LED blinks. This shall take about 8 seconds.

  • Page 72: Appendix

    Appendix A. Supported Lenses for Box Camera Provider Model No. RV0409D.IR Fujian Forecam Optics RV0515D.IR RV0820D.IR EVD03618F-IR EVD04218F-IR EVD06018F-IR EVETAR EVD08018F-IR EVD12018F-IR EVD16018F-IR Pentax TS3VP213ED-M...
