found, the packet will pass as is.
Description: A meaningful description of this rule
Incoming interface: The interface from which matching packets are received
Target address: The destination address of matching packets (optional)
Protocol: The used protocol of matching packets
Ports: The used UDP/TCP port of matching packets
Redirect to: The address to which matching packets shall be redirected
Redirect port: The port to which matching packets will be redirected
Figure 5.22.: Inbound NAPT
NAPT Outbound Rules
Outbound rules will modify the source section of IP packets and can be used to establish
1:1 NAT mappings but also to redirect packets to a specific service.
Description: A meaningful description of this rule
Incoming interface: The outgoing interface on which matching packets are leaving the
router
Source address: The source address of matching packets (optional)
Protocol: The used protocol of matching packets
