4. Installation

4.1. Environmental Conditions

The following precautions must be taken before installing a NB1600 router:
• Avoid direct solar radiation
• Protect the device from humidity, steam and aggressive fluids
• Guarantee sufficient circulation of air around the device
• The device is for indoor use only
Parameter
Input Voltage
Operating Temperature Range
Humidity
Altitude
Over-Voltage Category
Pollution Degree
Ingress Protection Rating

4.2. Installation of the Router

The NB1600 is designed for mounting it on a DIN rail or wall but it can also be put on
a worktop. Please consider the safety instructions and the environmental conditions in
chapter 2.

4.3. Installation of the SIM Card

For installing a SIM card, you will have to remove the SIM cover first. The card holder is
opened by sliding it slightly until it shifts up. You can now insert the SIM card, press the
holder and shift it back until it is locked. Ensure to have the contacts placed correctly,
otherwise the holder will not lock. The cover has to be closed again afterwards.
Rating
12 V to 48 V
DC
25 C to +70 C
0 to 95% (non-condensing)
up to 4000m
II
2
IP40
Table 4.1.: Operating Conditions
20
( 15% / +20%)
DC
