NB1600 User Manual

5.6. VPN

5.6.1. OpenVPN

OpenVPN Administration

Figure 5.24.: OpenVPN Administration
Tunnel Configuration
NetModule routers support one single server tunnel and up to four client tunnels. You
can specify tunnel parameters either in standard configuration or upload an expert mode
file which has been created in advance. Refer to chapter 5.6.1 to learn more about how
to manage clients and generate the files.
If the tunnel is operated in client mode, the following settings can be applied:
Operation mode: Specifies whether client or server mode should be used for this tunnel
Primary server address: The address of the primary server
Primary server port: The port of the primary server (1194 by default)
Secondary server address: The address of the secondary server address (optional) which
will be used in case the primary address cannot be reached
Secondary server port: The port of the secondary server (optional)
60
