Advanced Operation Instructions
for Washers HS-5008 / H5020
COIN CONTROL
GIRBAU, S.A.
Crta de Manlleu, km. 1
08500 VIC (Barcelona) • SPAIN
Tel. 34 93 8861100
Fax 34 93 8860785
girbau@girbau.es • www.girbau.com
For USA & CANADA:
CONTINENTAL GIRBAU Inc.
2500 State Road 44
WI 54904 Oshkosh • USA
Tel. 1(920) 231-8222
Fax 1(920) 231-4666
info@cont-girbau.com
www.cont-girbau.com
Advanced COIN
HS-5008
H5020
Rev. 02
Model
From Serial #
HS-5008
886.068
H5020
1.340.001
Cod. 411603
Rev. 02/0704

Advertisement

loading

Related Manuals for GIRBAU HS-5008

Summary of Contents for GIRBAU HS-5008

  • Page 1 Model From Serial # HS-5008 886.068 H5020 1.340.001 Advanced Operation Instructions for Washers HS-5008 / H5020 COIN CONTROL GIRBAU, S.A. Advanced COIN Crta de Manlleu, km. 1 HS-5008 08500 VIC (Barcelona) • SPAIN Tel. 34 93 8861100 H5020 Fax 34 93 8860785 girbau@girbau.es •...
  • Page 2 1.1 Control panel SERVICE REMOVAL, refer Operation 1.2 Loading the washing machine Instructions for Washers HS-5008 / H5020 COIN 1.3 Using the dispenser 1.4 Starting a program CONTROL ver. 1 (code 410712) supplied with the 1.5 Program application and contents washer...

  • Page 3: Modification Mode

    Advanced Mode 2. MODIFICATION mode basic configuration (when the machine is delivered) the access code to MODIFICATION is: 12341234 If the sequence set is correct, the display will show Pro, The MODIFICATION mode offers some menus, which corresponding to the first menu. allow the modification of programs contents, the price Keys 2 and 4 allow the selection of the precedent table management of the programs, the modification of...
  • Page 4 Advanced Mode Default programs contents. 2.2.2 GENERAL application (Non USA / CANADA) Pr - 1. S 31 min. Pr - 2. C 31 min. UPER WASH OLOR FAST PRESS - - - - - - - - - - - - - - - - - - - - - - - -...
  • Page 5 Advanced Mode 2.2.3. Phases definition. PHASES DEFINITION Pre-wash. Optional execution phase. Washing. Obligatory execution phase. The mixing of hot and cold water is permitted and/or water heating. First Rinse. Obligatory execution phase. Dosing of bleach included. Second Rinse. Optional execution phase. Third Rinse.

  • Page 6: Modification Mode

    Advanced Mode 2.2.5. Modification of a program Temperature of the washing phase Allows modifying the water temperature in the washing Access the MODIFICATION mode (section 2.1) The phase. In other phases, it is not possible to program the display will indicate Pro. water temperature.
  • Page 7 Advanced Mode 2.4. DEMO menu. Operating mode Rotation time with program accelerator Rotation time programmed in the phase. It is valued in minutes. It allows executing one of the four COIN programs with This time is started once the programmed temperature the possibility of reducing the program time.
  • Page 8 Advanced Mode 2.6. Modification operating parameters. MOD menu. The Mod menu allows the modification of the operation parameters of all the programs. The modifications carried out from Mod menu affect the four programs. Summary table of the changeable parameters: PARAMETER MODIFICATION OF OPTIONS Temperature displayed in Centigrade degrees...

  • Page 9: Access To Modification Mode

    Advanced Mode Prices allocation according to hour band Beep time Option possible only on machines with clock option It determines the beep duration when a program installed stopped by the STOP key restarts. The activation of option Hr-1 modifies the contents of Minimum programmable time: 10sec.

  • Page 10: Programs Price

    Advanced Mode Enter a combination of eight keys using the four central Push 3 key to display the current time. The hour of the keys in the control panel. system is showed in the display in the format: hh.mm The key pushed is displayed in the display with its (hour format: 24 hours).

  • Page 11: Cash Menu

    Advanced Mode To program the following time bands, you must repeat Repeat the procedure: programming a day of the week. this procedure from step 6 of this section. The STOP key allows the access to the superior Maximum number of time bands per day: four programming level.
  • Page 12 Advanced Mode To skip the MODIFICATION mode press STOP key twice with Pr-* on display. Example Example of rate programming. LOW RATE NORMAL HIGH RATE PROGRAM (LOW) RATE (Mid) (HIGH) ε ε ε 3.00 3.60 4.20 ε ε ε 2.40 3.00 3.60 ε...
