Oi Small Locker
Assembly Instructions -
Dimensions
Length - 35cm
Width - 38cm
Height - 64cm
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800
Please keep for future reference
719/3525
719/3532
Issue 1 - 12/03/2013
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Digitus DN-95311
Summary of Contents for Digitus DN-95311
- Page 1 Oi Small Locker Assembly Instructions - 719/3525 Please keep for future reference 719/3532 Dimensions Length - 35cm Width - 38cm Height - 64cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800 Issue 1 - 12/03/2013...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly components and tools listed on recommend the pages 2 and 3. this could cause damage. use of power drill/drivers inserting screws , plastic bags and separate them as this could damage the unit.
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: 0845 640 0800 Please check you have all the panels listed below Left side Back Door Right side (62.5 x 38cm) (52 x 28.5cm) (62.5 x 35cm) (62.5 x 38cm) shelf x2 fastener x2...
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. Band x 1 Tools required measu r e Ruler/tape measure...
- Page 5 Slide side onto back plate that their grooves interlock. Slide side onto back plate that their grooves interlock.
- Page 6 With the folded front edge away from back plate , place each shelf on the supports of the two sides.
- Page 7 Snap top plate onto the frame. Snap bottom plate onto the frame.
- Page 8 Insert bottom pin of door into the hole of bottom fastener . Holding the top pin down, move the top edge into the top Hold this pin down right corner until the top pin snaps into the hole. band Warning: The cabinet is heavy.
