Troubleshooting - ADJ Vortex 1200 User Instructions

Vortex 1200
Disconnect the unit from its power source. Locate the fuse holder on
the rear panel of the unit. Using a phillips-head screw driver unscrew
the fuse holder. Remove the bad fuse and replace with a new one.
Screw the fuse holder back into the unit containing the new fuse.
Vortex 1200
Due to fog residue, smoke, and dust cleaning the internal and exter-
nal optical lenses and mirror should be carried out periodically to
optimize light output. Cleaning frequency depends on the environ-
ment in which the fixture operates (I.e. smoke, fog residue, dust,
dew). In heavy club use we recommend cleaning on a monthly basis.
Periodic cleaning will ensure longevity, and crisp output.
1. Use normal glass cleaner and a soft cloth to wipe down the out-
side casing.
2. Use a brush to wipe down the cooling vents and fan grill.
3. Clean the external optics with glass cleaner and a soft cloth every
20 days.
4. Clean the internal optics with glass cleaner and a soft cloth every
30-60 days.
5. Always be sure to dry all parts completely before plugging the unit
back in.
Vortex 1200
Listed below are a few common problems the user may encounter,
with solutions.
Unit not responding to DMX:
1. Check that the DMX cables are connected properly and are
wired correctly (pin 3 is "hot"; on some other DMX devices
pin 2 may be 'hot'). Also, check that all cables are connected
to the right connectors; it does matter which way the inputs
and outputs are connected.
Unit does not respond to sound:
1. Quiet or high pitched sounds will not activate the unit.
2. Check the sound sensitivity level.
ADJ Products, LLC - www.adj.com - Vortex 1200 User Manual Page 32
Fuse Replacement
Cleaning

Troubleshooting

Vortex 1200
Unpacking:
Thank you for purchasing the Vortex 1200 by ADJ Prod-
ucts, LLC. Every Vortex 1200 has been thoroughly tested and has
been shipped in perfect operating condition. Carefully check the ship-
ping carton for damage that may have occurred during shipping. If the
carton appears to be damaged, carefully inspect your fixture for any
damage and be sure all accessories necessary to operate the unit has
arrived intact. In the case damage has been found or parts are miss-
ing, please contact our toll free customer support number for further
instructions. Do not return this unit to your dealer without first contact-
ing customer support.
Introduction:
The Vortex 1200 is a DMX intelligent, moving head,
moonflower LED fixture, with zoom effect. This fixture is a great piece
for nightclubs, bars, and stage productions. This unit can be used as
a stand alone unit, or in a Master/Slave configuration. The unit has 3
operating modes; show mode, sound active, and DMX controlled. This
fixture is suitable for theaters, studios, retail stores, and other similar
locations.
Customer Support:
ADJ Products, LLC provides a toll free cus-
tomer support line, to provide set up help and to answer any question
should you encounter problems during your set up or initial operation.
You may also visit us on the web at www.adj.com for any comments
or suggestions. Service Hours are Monday through Friday 8:00 a.m. to
4:30 p.m. Pacific Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning!
To prevent or reduce the risk of electrical shock or fire, do
not expose this unit to rain or moisture.
Caution!
There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
ADJ Products, LLC.
PLEASE recycle the shipping carton when ever possible.
ADJ Products, LLC - www.adj.com - Vortex 1200 User Manual Page 2
