Vortex 1200
Channel Value
1 0 - 255
2 0 - 255
3 0 - 255
4 0 - 255
5 0 - 255
6 0 - 255
7
0 - 19
20 - 29
30 - 39
40 - 49
50 - 59
60 - 69
70 - 79
80 - 89
90 - 99
100 - 109
110 - 119
120 - 129
130 - 139
140 - 149
150 - 159
160 - 169
170 - 179
180 - 189
190 - 199
200 - 209
210 - 219
220 - 229
230 - 239
240 - 255
8 0 - 255 COLOR MACRO SPEED SLOW - FAST
9
0 - 127
ADJ Products, LLC - www.adj.com - Vortex 1200 User Manual Page 21
15 Channel Mode
Function
PAN
TILT
RED 0% - 100%
GREEN 0% - 100%
BLUE 0% - 100%
WHITE 0% - 100%
COLOR MACROS
OFF
MACRO 1
MACRO 2
MACRO 3
MACRO 4
MACRO 5
MACRO 6
MACRO 7
MACRO 8
MACRO 9
MACRO 10
MACRO 11
MACRO 12
MACRO 13
MACRO 14
MACRO 15
MACRO 16
MACRO 17
MACRO 18
MACRO 19
MACRO 20
MACRO 21
MACRO 22
MACRO 23
EFFECT ROTATION
INDEXING 0-360 DEGREES
Vortex 1200

Manual Test

- With this function you can manually test
the individual features.
1. Press the MENU button until "Manual Test" is displayed,
press ENTER.
2. Use the UP or DOWN buttons to find the functions that you
wish to test.
3. Once you find a function you wish to test, press the ENTER
button, and the displayed value will begin to flash. You can now
adjust the values by pressing the UP and DOWN buttons. Once
you have finished testing that function press the ENTER button.
4. To exit the manual test mode, press the MENU button.
Auto Test
- This function will run a self test program.
1. Press the MENU button until "Auto Test" is displayed, press
ENTER.
2. The fixture will now run a self test. Press the MENU button to
exit.
Fixture Temp.
- With this function you can display the
current temperature of the unit.
1. Press the MENU button until "Fixture Temp." is displayed,
press ENTER.
2. The current temperature of the fixture will now be displayed.
Press MENU to exit.

Fan Mode

- With this function you can control the fan
operation.
1. Press the MENU button until "Fan Mode" is displayed, press
ENTER.
2. Either "Auto", "Low", or "High" will now be displayed. Press
ADJ Products, LLC - www.adj.com - Vortex 1200 User Manual Page 14
