Dmx Address; Channel Mode; Show Mode - ADJ Vortex 1200 User Instructions

Vortex 1200
Channel Value
9
190 - 199
200 - 209
210 - 219
220 - 229
230 - 239
240 - 255
10 0 - 255 COLOR MACRO SPEED SLOW - FAST
11
0 - 127
128 - 189 CLOCKWISE ROTATION FAST - SLOW
190 - 193
194 - 255 CLOCKWISE ROTATION SLOW - FAST
12
0 - 19
20 - 39
40 - 59
60 - 79
80 - 99
100 - 119
120 - 139
140 - 159
160 - 179
180 - 199
200 - 219
220 - 255
13 0 - 255
14
0 - 7
8 - 15
16 - 23
24 - 31
32 - 39
40 - 47
ADJ Products, LLC - www.adj.com - Vortex 1200 User Manual Page 25

17 Channel Mode

Function
COLOR MACROS
MACRO 18
MACRO 19
MACRO 20
MACRO 21
MACRO 22
MACRO 23
EFFECT ROTATION
INDEXING 0-360 DEGREES
STOP
STROBING
OPEN
STROBING SLOW - FAST
MACRO 1 STROBE
MACRO 2 STROBE
MACRO 3 STROBE
MACRO 4 STROBE
MACRO 5 STROBE
STROBE EFFECT 1
STROBE EFFECT 2
STROBE EFFECT 3
STROBE EFFECT 4
OPEN
MASTER DIMMER
PAN/TILT MACROS
NO FUNCTION
MACRO 1
MACRO 2
MACRO 3
MACRO 4
MACRO 5
Vortex 1200
System Menu: When making adjustments press ENTER to
confirm your setup then press and hold the MENU button
for at least 3 seconds. To exit without making any adjust-
ments press the MENU button. The display will lock after 30
seconds, press the MENU button for 3 seconds to unlock.

DMX Address

- Set the DMX Address -
1. Press the MENU button until "DMX Address" is displayed,
press ENTER.
2. "XXX" will now be displayed, "XXX" represents the displayed
address. Press the UP or DOWN buttons to find your desired
address.
3. Press ENTER to confirm, and then press and hold the MENU
button
for at least three seconds
Channel Mode
- This will let you select your desired
DMX Channel mode.
1. Press the MENU button until "Channel Mode" is displayed,
press ENTER.
2. "XXChan" will now be displayed, "XX" represents the displayed
DMX channel mode. Press the UP or DOWN buttons to find your
desired Channel mode.
3. Press ENTER to confirm.

Show Mode

- Show modes 1 - 4 (Factory Shows).
1. Press the MENU button until "Show Mode" is displayed, press
ENTER.
2. "Show X" will now be displayed, "X" representing a number
between 1-4. Press the UP or DOWN buttons to find your desired
show and press ENTER to confirm. After pressing ENTER, press
and hold the MENU button for at least 3 seconds to activate.
ADJ Products, LLC - www.adj.com - Vortex 1200 User Manual Page 10
System Menu
to assign.
