t – Button number (memory) [1-4]
nn – telephone number up to 16 digits to be stored. Refer to the table
for other choices.
The number stored in parameter 1 is the number for the first group or
the number for Day mode.
Parameter Value
2 t nn...
t – Button number (memory) [1-4]
nn – telephone number up to 16 digits to be stored. Refer to the table
for other choices.
The number stored in parameter 2 is the number for the second group
or the number for Night mode
Note: The switchover to Day/Night mode remains set in the unit even after
line disconnection.

5.2 Relay

Paramet
Value
er
31 r m
m – relay mode [ 1-2]
m=1 relay mode – relay will close on command or password for ss period (used for
electrical locks, gate opening, etc.)
m=2 button mode – (activated by button press e.g. external bell).
Paramet
Value
er
r
32
hhhhhh
r
33
hhhhhh
r
34
hhhhhh
hhhhhh – password for relay closing from buttons [2 to 6 digits]
The 3 passwords are controlled by Day/Night; the combination is entered using the unit
buttons. It is influenced by the setting of Relay mode and Day/Night switchover. When set
to 2-group mode the unit is permanently in DAY mode.
Follow these rules when choosing password combination:
Select passwords carefully, to prevent their discovery from wear on buttons caused by
§
frequent use.
Select the first password button from infrequently-used buttons for direct dialling (-
§
extends choice time)(-not valid for keyboard).
Linkcom France
11 rue du Soleil Levant 92140 CLAMART
Description
No. nn under
button t
Description
Relay mode
Description
External access code in
DAY + NIGHT mode
External access code in
DAY mode
External access code in
NIGHT mode
Default Exam.1 Exam.2
- -
Defaul Exam.
Exam.2
t 1
1 1
Defaul Exam. Exam.
t 1 2
- 1212 1324
- 2211 2211
- 1122 1122
parameter
0 - 9
#
∗
Recall
Pause
-
parameter choice
0 - 9
#
∗
Recall
Pause
2
