3.3.1

Outgoing call

An "outgoing" call is a call from the unit (i.e. when a visitor presses a button). Once the
visitor has pressed a button a telephone will ring. On answering the telephone, you will be
able to converse with the visitor. 10 seconds before the maximum call duration (parameter
52) the unit will emit a tone to warn that the call will end. The call may be extended by
pressing the key as set in parameter 42. A code may be dialled to close the relay (parameter
35), releasing the lock. Hanging up the telephone will end the call, as will the busy tone from
the PBX.
3.3.2

Incoming call

An incoming call is a call to the unit. After dialling the PBX extension number to which the
unit is connected, the unit will ring for the set number of rings (parameter 51), the unit will
lift up and it is possible to speak. The possibilities are the same as with outgoing call
(Chapter 3.3.1). It is also possible to switch between Day and Night service.
If, within the first 10 seconds, the service password is entered, the unit will switch to
•
programming mode and voice communication will cease.
During an incoming call it is possible to restrict relay control (parameter 37). This can
•
be useful in some special applications.

4 Parameter programming

4.1 Programming from a telephone by DTMF

4.1.1

Entering programming mode

The SlimDoorPhone may be set to programming mode in two ways:
1. by password – dial the unit's number
telephone number, if connected to a PSTN line)
Pick up line tone – see Chapter 3.1 page8). Within 10 seconds dial #xxxx, where
xxxx is the password for entry to programming and, if OK, the registration tone for
programming mode will sound, and afterwards the Programming tone is heard (see
Chapter 3.1 page 8).
2. by "SERVICE" switch – dial the unit in the same way as in 1, but when the SERVICE
switch is connected, the unit will automatically enter programming mode. You will
hear the call connection confirmation tone, the confirmation tone for programming
mode and afterwards the Programming tone is heard. (see Chapter 3.1 page 8).
4.1.2 Parameter programming
The initial state for programming is signalled by the programming confirmation tone.
The unit will always revert to this state after 5 seconds of inactivity, even if you have started
to program a parameter.
When programming, there are two types of parameters. The majority are parameters
with a fixed length. The parameter is always saved immediately and is confirmed by
Parameter Confirmation tone. Parameters with variable length (parameters 1,2,32,33,34)
are saved after the inactivity period expires (5 sec). However, a varaible length parameter
will be saved immediately when maximum permitted number of digits is reached. For
parameters 1 and 2 the maximum number of digits is 16, and for parameters 32,33,34 it is
6.
If, during programming, you enter a number which is not allowable, then the unit
immediately emits an error tone. The parameter will not be recorded or changed, and the
unit will return to its initial programming state and it will be possible to repeat the parameter
setting or program another parameter.
The unit stays inactive in programming mode for 34 seconds and will then automatically
hang up. Every time a DTMF tone is dialled, this period is reset. Alternatively, parameter 9
may also be selected to end programming mode.
Linkcom France
11 rue du Soleil Levant 92140 CLAMART
(either extension number, if connected to a PBX or
. The unit will answer (you will hear the
