DD-120 Owner's Manual
1 x 2 DVI Distribution Amplifier
TM
PureLink
535 East Crescent Avenue
Ramsey, NJ 07446
USA
Tel: +1.201.488.3232
Fax: +1.201.621.6118
E-mail:
sales@purelinkav.com
www.purelinkav.com
For order support, please contact your local dealer.
For technical support, please contact us at
support@purelinkav.com
Advertisement
Related Manuals for PureLink DD-120
Summary of Contents for PureLink DD-120
- Page 1 DD-120 Owner’s Manual 1 x 2 DVI Distribution Amplifier PureLink 535 East Crescent Avenue Ramsey, NJ 07446 Tel: +1.201.488.3232 Fax: +1.201.621.6118 E-mail: sales@purelinkav.com www.purelinkav.com For order support, please contact your local dealer. For technical support, please contact us at support@purelinkav.com...
-
Page 2: Table Of Contents
PureLink by Dtrovision Table of Contents 1-1 Package Contents 1-2 General Specification 1-3 Operation and Reliability Specifications 1-4 Main Features 1-5 Video Connection 1-6 Mechanical Specification 1-7 Technical Specification 1-8 Warranty Information p.10 1-9 Troubleshooting p.11... -
Page 3: Package Contents
PureLink by Dtrovision 1-1 Package Contents Please make sure all of the following items are included in the package: 1) DD-120 Unit 2) DC 5V 2A Power supply adapter... -
Page 4: General Specification
PureLink DD-120 distribution amplifier is designed to distribute a single PC digital signal into multiple monitor without any degradation of original signal quality or distortion of the image. In addition, a dedicated IC chipset makes DD-120 capable of amplifying and distributing highest quality of video signal and true HD digital contents. -
Page 5: Operation And Reliability Specifications
PureLink by Dtrovision 1-3 Operation and Reliability Specification 1. Operating Environment Temperature : 50F ~ 104F (10℃~ 40℃) Humidity : 10% ~ 80% Altitude : 3,000m Max. 2. Transit Environment Temperature : -13F ~ 140F (-25℃~ 60℃) Humidity : 5% ~ 95% Altitude : 15,000m Max. -
Page 6: Main Features
PureLink by Dtrovision 1-4 Main Features 1. High Quality Picture - No Signal Loss and Digital Noise Free Our Distribution Amplifiers are built to deliver the highest quality picture preserving the native resolutions of the video sources without any signal loss. At the same time, the digital noises that may affect the picture quality will be eliminated. -
Page 7: Video Connection
Video Connection 1. Turn off the whole system before connecting. 2. Connect your video source’s DVI output port to the DD-120’s DVI input port using standard DVI cables (not included). 3. Connect your DVI display’s DVI input port to DD-120’s DVI output port. -
Page 8: Mechanical Specification
PureLink by Dtrovision 1-6 DD-120 Mechanical Specification DD-120 Dimension: 7.5’ (W) x 4.25’ (D) x 1.37’ (H) Inch / 1 lb On/Off switch: Power Switch POWER: Power Indicator EDID: EDID Indicator EDID S/W: EDID save Button OUT #1, #2: Output Signal Detection LED light DC +5V: Power Receptacle INPUT: DVI –D connector... -
Page 9: Technical Specification
PureLink by Dtrovision 1-7 Technical Specification Frequency bandwidth: 1.65 Gbps (Single Link) Supporting Graphic Resolution: Supports all standard display resolutions up to WUXGA (2048 X 1080 / 1920 X 1200 @ 60Hz), UXGA, SXGA, XGA, VGA & 480i/p, 720i/p, 1080i/p) - Page 10 PureLink shall not be liable for any damages whatsoever caused by Product or the failure of Product to perform, including incidental or consequential damages. PureLink shall not be liable for any claim made by a third party or made by the purchaser for a third party.
-
Page 11: Troubleshooting
PureLink by Dtrovision 1-9 Troubleshooting Problem Solution Distribution Amplifier Make sure the 5V power is plugged in the back of the unit. does not operate Check to see if the power LED light is on. No picture(or signal) 1. In case your video source is HDCP enabled, make sure Or Poor picture your video display (HDTV) is HDCP compliant.
