DD-250 Owner's Manual
2 x 5 DVI Distribution Amplifier
TM
PureLink
535 East Crescent Avenue
Ramsey, NJ 07446
USA
Tel: +1.201.488.3232
Fax: +1.201.621.6118
E-mail:
sales@purelinkav.com
www.purelinkav.com
For order support, please contact your local dealer.
For technical support, please contact us at
support@purelinkav.com
Advertisement
Related Manuals for PureLink DD-250
Summary of Contents for PureLink DD-250
- Page 1 DD-250 Owner’s Manual 2 x 5 DVI Distribution Amplifier PureLink 535 East Crescent Avenue Ramsey, NJ 07446 Tel: +1.201.488.3232 Fax: +1.201.621.6118 E-mail: sales@purelinkav.com www.purelinkav.com For order support, please contact your local dealer. For technical support, please contact us at support@purelinkav.com...
-
Page 2: Table Of Contents
PureLink by Dtrovision Table of Contents 1-1 Package Contents 1-2 General Specification 1-3 Environmental and Reliability Specifications 1-4 Main Features 1-5 Setup / Installation 1-6 Mechanical Specification 1-7 Technical Specification 1-8 Warranty Information p.10 1-9 Troubleshooting p.11... -
Page 3: Package Contents
PureLink by Dtrovision 1-1 Package Contents Owner’s Manual... -
Page 4: General Specification
1-2 General Specification The PureLink DD-250 2x5 Distribution Amplifier is designed to distribute up to 5 DVI outputs (PC, AVR) at full 1080p HD, to as many as 5 HD display monitors with no degradation of the original signal quality or distortion of the image. - Page 5 PureLink by Dtrovision 1-3 Operation and Reliability Specification 1. Operating Environment Temperature : 10℃~ 40℃ Humidity : 10% ~ 80%, non-condensing Altitude : maximum 3,000m 2. Transit Environment Temperature : -25℃~ 60℃ Humidity : 5% ~ 95%, non-condensing Altitude : maximum 15,000m 3.
-
Page 6: Main Features
2. Signal Amplification for signal reliability and long length signal transmission PureLink’s 12V power adapter supplies adequate power to amplify the video signals from the video source. This is necessary as the overall length from the video source to the displays is longer when using the distribution amplifiers (distance from the video source to the distribution amplifier + distance from the distribution amplifier to the display). -
Page 7: Setup / Installation
4. Plug the 12V power adapter in to the DD-250 5. You may start turning on your system in the following order : DD-250 -> Display ->Video Source. 6. Input LED #1,2 and Output LED # 1~5 will be lit if everything is properly installed. - Page 8 14. 1080p Multi Please note that all DD-250 are normally set to 1920x1080p 2ch audio as a default setting when released from the factory. If the default setting does not work for your system, please program either an external EDID or an EDID from our pre-...
-
Page 9: Mechanical Specification
PureLink by Dtrovision 1-6 Mechanical Specification Dimension DD-250 : 13.7(W) x 6.4(D) x 1.7(H) Inch, Weight: 3.3 lbs Front Panel: MENU Button : Menu selection ENTER Button : Save/ Select SELECT Button : Input selection IN 1, 2 : Input status LED... -
Page 10: Technical Specification
PureLink by Dtrovision 1-7 Technical Specification Frequency bandwidth: 2.65 Gbps (Single Link) Supporting Graphic Resolution: Supports all standard display resolutions up to WUXGA (2048 X 1080 / 1920 X 1200 @ 60Hz), UXGA, SXGA, XGA, VGA & 480i/p, 720i/p, 1080i/p) -
Page 11: Warranty Information
Dealer. PureLink shall repair or replace the Product if it develops a material fault during the period of warranty, on condition that i) the Product has only been subject to normal use in a domestic or commercial environment in... -
Page 12: Troubleshooting
20ft. Exceeding 20ft. with copper based cables will result in no or poor picture quality. To extend beyond 20ft, please use fiber optic DVI extension cables such as the Purelink HDX II series 3. Use high quality DVI cables. 4. If you are using computers, try other refresh rate settings.
