- Page 1 HD-120 Owner’s Manual 1 x 2 HDMI Distribution Amplifier Dtrovision LLC E-mail: mpark@dtrovision.com 9A Bergen Turnpike www.purelinkav.com Little Ferry, NJ 07643 www.dtrovision.com Tel: 201.488.3232 For technical support, contact: Fax: 201.621.6118 support@dtrovision.com...
-
Page 2: Table Of Contents
PureLink by Dtrovision Table of Contents 1-1 Package Contents 1-2 General Specification 1-3 Operation and Reliability Specifications 1-4 Main Features 1-5 Video Connection 1-6 Mechanical Specification 1-7 Technical Specification 1-8 Warranty Information p.10 1-9 Troubleshooting p.11... -
Page 3: Package Contents
PureLink by Dtrovision 1-1 Package Contents Please make sure all of the following items are included in the package: 1) HD-120 Unit 2) DC 5V 2A Power supply adapter 3) Owner’s Manual... -
Page 4: General Specification
PureLink HD-120 distribution amplifier is designed to distribute a single PC digital signal into multiple monitor without any degradation of original signal quality or distortion of the image. In addition, a dedicated IC chipset makes HD-120 capable of amplifying and distributing highest quality of video signal and true HD digital contents. -
Page 5: Operation And Reliability Specifications
PureLink by Dtrovision 1-3 Operation and Reliability Specification 1. Operating Environment Temperature : 50F ~ 104F (10℃~ 40℃) Humidity : 10% ~ 80% Altitude : 3,000m Max. 2. Transit Environment Temperature : -13F ~ 140F (-25℃~ 60℃) Humidity : 5% ~ 95% Altitude : 15,000m Max. -
Page 6: Main Features
2300ft using our fiber optical HDMI cables. 3. HDMI (High Definition Multimedia Interface) v 1.3 HD-120 is consisting of HDMI input and output ports, and it is conforms to HDMI 1.3 standard. 4. HDCP (High-bandwidth Digital Content Protection) Compliant Our HDMI distribution amplifiers are fully HDCP compliant. -
Page 7: Video Connection
Video Connection 1. Turn off the whole system before connecting. 2. Connect your video source’s HDMI output port to the HD-120’s HDMI input port using standard HDMI cables (not included). 3. Connect your HDMI display’s HDMI input port to HD-120’s HDMI output port. -
Page 8: Mechanical Specification
PureLink by Dtrovision 1-6 HD-120 Mechanical Specification HD-120 Dimension: 7.1’ (W) x 4.25’ (D) x 1.37’ (H) Inch / 1 lb On/Off switch: Power Switch POWER: Power Indicator 1 x 2 HDMI Distribution Amplifier HD-120 EDID: EDID Indicator EDID S/W: EDID save Button... -
Page 9: Technical Specification
PureLink by Dtrovision 1-7 Technical Specification Frequency bandwidth: 1.65 Gbps (Single Link) Supporting Graphic Resolution: Supports all standard display resolutions up to WUXGA (2048 X 1080 / 1920 X 1200 @ 60Hz), UXGA, SXGA, XGA, VGA & 480i/p, 720i/p, 1080i/p) - Page 10 1-8 Warranty 2 (two) Year Warranty Dtrovision warrants this PureLink HD-120 to be free from defects in workmanship and materials, under normal use and service, for a period of two (2) year from the date of purchase from Dtrovision or its authorized resellers.
-
Page 11: Troubleshooting
To extend beyond 20ft, please use fiber optical HDMI extension cables such as PureLink OC series. 3. Use high quality HDMI cables. 4. If you are using computers, try other refresh rate settings. - Page 12 PureLink by Dtrovision FCC/CE Statement This device complies with part 15 of FCC Rules and EN 55022/55024/61000-3 for CE certification. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must not accept any interference received, including interference that may cause undesired operation.
