DD-2100
Owner's Manual
2X10 DVI Distribution Amplifier
TM
PureLink
535 East Crescent Avenue
Ramsey, NJ 07446
USA
Tel: +1.201.488.3232
Fax: +1.201.621.6118
E-mail:
sales@purelinkav.com
www.purelinkav.com
For order support, please contact your local dealer.
For technical support, please contact us at
support@purelinkav.com
Advertisement
Related Manuals for PureLink DD-2100
Summary of Contents for PureLink DD-2100
- Page 1 DD-2100 Owner’s Manual 2X10 DVI Distribution Amplifier PureLink 535 East Crescent Avenue Ramsey, NJ 07446 Tel: +1.201.488.3232 Fax: +1.201.621.6118 E-mail: sales@purelinkav.com www.purelinkav.com For order support, please contact your local dealer. For technical support, please contact us at support@purelinkav.com...
-
Page 2: Package Contents
PureLink by Dtrovision Package Contents Each Purelink DVI Distributor package includes the following items; DD-2100 DVI Distribution Amplifier Unit x 1 12V Power Supply Adapter x 1 AC Power Cord x 1 User manual x 1 ... -
Page 3: Table Of Contents
PureLink by Dtrovision CONTENTS Contents Description, General Specification Environmental and Reliability Specifications 1-3 Main Features Video Connection Mechanical Specification Technical Specification Warranty Information Troubleshooting... -
Page 4: General Specification
PureLink by Dtrovision General Specification Purelink DD-2100 regenerates two digital video sources into multiple digital displays. ITEM DESCRIPTION Model Name DD-2100 Input Signal DVI Single Link , 2port Output Signal DVI Single Link , 10ports, Supports all standard display resolutions up to... - Page 5 PureLink by Dtrovision Operation and Reliability Specification 1 Operating Conditions Temperature : 10℃~ 40℃ Humidity : 10% ~ 80%, non-condensing Altitude : maximum 3,000m 2 Transportation Conditions Temperature : -25℃~ 60℃ Humidity : 5% ~ 95%, non-condensing Altitude : maximum 15,000m...
-
Page 6: Main Features
PureLink by Dtrovision Main Features High Quality Picture - No Signal Loss and Digital Noise Free Our Distribution Amplifiers are built to deliver the highest quality picture preserving the native resolutions of the video sources without any signal loss. At the same time, the digital noises that may affect the picture quality will be eliminated. -
Page 7: Video Connection
II. Internal EDID Set up (Factory Default Setting) 1, Unplug all DVI cables 2, Turn on DD-2100 3, Press ”INTERNAL EDID” button on the front of the DD-2100 for 3 sec until RED LED light is on. 4, Turn off DD-2100 5, Reconnect all device following above “Video Connection”... -
Page 8: Mechanical Specification
PureLink by Dtrovision Mechanical Specification Dimensions DD-2100 : 425(W) x 165(D) x 45(H) mm DC 12V : DC Power Input (+12 V) POWER : Power On / Off Switch CH1 : Input Channel 1 Indication LED CH2 : Input Channel 2 Indication LED... -
Page 9: Technical Specification
PureLink by Dtrovision Technical Specification Frequency bandwidth: 1.65 Gbps (Single Link) Supporting Graphic Resolution: Supports all standard display resolutions up to WUXGA (2048 X 1080 / 1920 X 1200 @ 60Hz), UXGA, SXGA, XGA, VGA & 480i/p, 720i/p, 1080i/p) Inputs: DVI x 2 Output: DVI x 10 Power supply: DC 12V, 3A Adapter included. - Page 10 PureLink shall not be liable for any damages whatsoever caused by Product or the failure of Product to perform, including incidental or consequential damages. PureLink shall not be liable for any claim made by a third party or made by the purchaser for a third party.
-
Page 11: Troubleshooting
PureLink by Dtrovision Troubleshooting Problem Solution Distribution Amplifier does Make sure the 12V power is plugged in the back of the unit. not operate Check to see if the power LED light is on. 1. In case your video source is HDCP enabled, make sure your video display(HDTV) is HDCP compliant.
