- Page 1 Owner´s Manual HD-250 2 x 5 HDMI Distribution Amplifier...
-
Page 2: Table Of Contents
Table of Contents Page Package Contents General Specifications Environmental and Reliability Specifications Main Features Setup / Installation Mechanical Specifications Technical Specifications Warranty Information Troubleshooting... -
Page 3: Package Contents
HD-250 Package Contents Please make sure all of the following items are included in the package: HD-250 unit DC 12V 4A Power supply adapter AC Cord Rack ears Owner’s Manual... -
Page 4: General Specifications
General Specifications The PureLink HD-250 2x5 Distribution Amplifier is designed to distribute up to 2 HDMI outputs (PC, AVR) at full 1080p HD, to as many as 5 HD display monitors with no degradation of the original signal quality or distortion of the image. -
Page 5: Environmental And Reliability Specifications
Environmental and Reliability Specifications 1 Operating Conditions Temperature : 10℃~ 40℃ Humidity : 10% ~ 80%, non-condensing Altitude : maximum 3,000m 2 Transportation Conditions Temperature : -25℃~ 60℃ Humidity : 5% ~ 95%, non-condensing Altitude : maximum 15,000m 3 Storage Conditions Temperature : -20℃~ 45℃... -
Page 6: Main Features
HDMI (High-Definition Multimedia Interface) v1.3 The HD-250 is fully compatible with HDMI version 1.3 and it can also be used for DVI applications by using additional DVI to HDMI coupler or cable. HDCP (High-bandwidth Digital Content Protection) Compliant PureLink’s HDMI distribution amplifiers are fully HDCP compliant. - Page 7 HDMI cable. 4. Plug the 12V power adapter in to the HD-250 5. You may start turning on your system in the following order : HD-250 -> Display ->Video Source. 6. Input LED #1,2 and Output LED # 1~5 will be lit if everything is properly installed.
- Page 8 7. 1400x1050 14. 1080p Multi Please note that all HD-250 are normally set to 1920x1080p 2ch audio as a default setting when released from the factory. If the default setting does not work for your system, please program either an external EDID or an EDID from our pre-loaded selections .
-
Page 9: Mechanical Specifications
Mechanical Specifications Dimension HD-250 : 11(W) x 6.3(D) x 2.4(H) Inch, Weight: 3.3 lbs Front Panel: MENU Button : Menu selection ENTER Button : Save/ Select SELECT Button : Input selection IN 1, 2 : Input status LED OUT 1~5 : Output status LED... -
Page 10: Warranty Information
If a product does not work as warranted during the applicable warranty period, PureLink shall, at its option and expense, repair the defective product or part, deliver to customer an equivalent product or part to replace the defective item, or refund to customer the purchase price paid for the defective product. -
Page 11: Troubleshooting
Any replaced or repaired product or part has a ninety (90) day warranty or the reminder of the initial warranty period, whichever is longer. PureLink shall not be responsible for any software, firmware, information, or memory data of customer contained in, stored on, or integrated with any products returned to PureLink for repair under warranty or not. - Page 12 To extend beyond 20ft, please use fiber optic HDMI extension cables such as the Purelink HDX II series 3. Use high quality HDMI cables. 4. If you are using computers, try other refresh rate settings. Most HDTV’s have refresh rate of 48Hz and computer’s video cards are usually set at higher refresh rate.
- Page 13 PureLink GmbH Hovesaatstraße 6 D-48432 Rheine Telefon: +49 (0) 5971 800 299-0 Fax: +49 (0) 5971 800 299-99 E-mail: info@purelink.de www.purelink.de For order support, please contact your local dealer. For technical support, please contact us at support@purelink.de...
