- Page 1 DD-120 Owner’s Manual 1 x 2 DVI Distribution Amplifier Dtrovision LLC E-mail: mpark@dtrovision.com 9A Bergen Turnpike www.purelinkav.com Little Ferry, NJ 07643 Tel: 201.488.3232 For technical support, contact: Fax: 201.621.6118 support@dtrovision.com...
-
Page 2: Table Of Contents
PureLink by Dtrovision Table of Contents 1-1 Package Contents 1-2 General Specification 1-3 Operation and Reliability Specifications 1-4 Main Features 1-5 Video Connection 1-6 Mechanical Specification 1-7 Technical Specification 1-8 Warranty Information p.10 1-9 Troubleshooting p.11... -
Page 3: Package Contents
PureLink by Dtrovision 1-1 Package Contents Please make sure all of the following items are included in the package: 1) DD-120 Unit 2) DC 5V 2A Power supply adapter... -
Page 4: General Specification
PureLink DD-120 distribution amplifier is designed to distribute a single PC digital signal into multiple monitor without any degradation of original signal quality or distortion of the image. In addition, a dedicated IC chipset makes DD-120 capable of amplifying and distributing highest quality of video signal and true HD digital contents. -
Page 5: Operation And Reliability Specifications
PureLink by Dtrovision 1-3 Operation and Reliability Specification 1. Operating Environment Temperature : 50F ~ 104F (10℃~ 40℃) Humidity : 10% ~ 80% Altitude : 3,000m Max. 2. Transit Environment Temperature : -13F ~ 140F (-25℃~ 60℃) Humidity : 5% ~ 95% Altitude : 15,000m Max. -
Page 6: Main Features
PureLink by Dtrovision 1-4 Main Features 1. High Quality Picture - No Signal Loss and Digital Noise Free Our Distribution Amplifiers are built to deliver the highest quality picture preserving the native resolutions of the video sources without any signal loss. At the same time, the digital noises that may affect the picture quality will be eliminated. -
Page 7: Video Connection
Video Connection 1. Turn off the whole system before connecting. 2. Connect your video source’s DVI output port to the DD-120’s DVI input port using standard DVI cables (not included). 3. Connect your DVI display’s DVI input port to DD-120’s DVI output port. -
Page 8: Mechanical Specification
PureLink by Dtrovision 1-6 DD-120 Mechanical Specification DD-120 Dimension: 7.5’ (W) x 4.25’ (D) x 1.37’ (H) Inch / 1 lb On/Off switch: Power Switch POWER: Power Indicator EDID: EDID Indicator EDID S/W: EDID save Button OUT #1, #2: Output Signal Detection LED light DC +5V: Power Receptacle INPUT: DVI –D connector... -
Page 9: Technical Specification
PureLink by Dtrovision 1-7 Technical Specification Frequency bandwidth: 1.65 Gbps (Single Link) Supporting Graphic Resolution: Supports all standard display resolutions up to WUXGA (2048 X 1080 / 1920 X 1200 @ 60Hz), UXGA, SXGA, XGA, VGA & 480i/p, 720i/p, 1080i/p) - Page 10 1-8 Warranty 2 (Two) Year Warranty Dtrovision warrants this PureLink DD-120 to be free from defects in workmanship and materials, under normal use and service, for a period of two (2) year from the date of purchase from Dtrovision or its authorized resellers.
-
Page 11: Troubleshooting
PureLink by Dtrovision 1-9 Troubleshooting Problem Solution Distribution Amplifier Make sure the 5V power is plugged in the back of the unit. does not operate Check to see if the power LED light is on. No picture(or signal) 1. In case your video source is HDCP enabled, make sure Or Poor picture your video display (HDTV) is HDCP compliant.
