- Page 1 HD-250 2 x 5 HDMI Distribution Amplifier Owner’s Manual PureLink 535 East Crescent Avenue Ramsey, NJ 07446 Tel: +1.201.488.3232 Fax: +1.201.621.6118 E-mail: sales@purelinkav.com www.purelinkav.com For order support, please contact your local dealer.
- Page 2 For technical support, please contact us at support@purelinkav.com...
-
Page 3: Table Of Contents
Table of Contents Page Package Contents General Specifications Environmental and Reliability Specifications Main Features Setup / Installation Mechanical Specifications Technical Specifications Warranty Information Troubleshooting... -
Page 4: Package Contents
HD-250 Package Contents Please make sure all of the following items are included in the package: HD-250 unit DC 12V 4A Power supply adapter AC Cord Rack ears Owner’s Manual... -
Page 6: General Specifications
The HD-250’s compact, durable and low power-consumption design makes it an ideal solution for connection of the high definition video and audio content in digital display devices, such as an LCD, Plasma, LED, Projector, etc. In addition, the HD-250 offers quick and easy plug-and-play installation for commercial or residential systems. -
Page 8: Environmental And Reliability Specifications
Environmental and Reliability Specifications 1. Operating Conditions Temperature : 10℃~ 40℃ Humidity : 10% ~ 80%, non-condensing Altitude : maximum 3,000m 2. Transportation Conditions Temperature : -25℃~ 60℃ Humidity : 5% ~ 95%, non-condensing Altitude : maximum 15,000m 3. Storage Conditions Temperature : -20℃~ 45℃... -
Page 9: Main Features
2300ft using our fiber optic HDMI extenders or cables. HDMI (High-Definition Multimedia Interface) v1.3 The HD-250 is fully compatible with HDMI version 1.3 and it can also be used for DVI applications by using additional DVI to HDMI coupler or cable. -
Page 10: Setup / Installation
HDMI cable. 4. Plug the 12V power adapter in to the HD-250 5. You may start turning on your system in the following order : HD-250 -> Display ->Video Source. 6. Input LED #1,2 and Output LED # 1~5 will be lit if everything is properly installed. - Page 11 1. Select the Input number ( make sure the input LED light is lit ) 2. Connect your display device to output #1 3. Go to the MENU screen and press ENTER button to save your EDID into the HD-250 EXT EDID LOAD EXT EDID LOAD <- When Input# 1 is selected...
-
Page 12: Mechanical Specifications
Please note that all HD-250 are normally set to 1920x1080p 2ch audio as a default setting when released from the factory. If the default setting does not work for your system, please program either an external EDID or an EDID from our pre-loaded selections . -
Page 13: Technical Specifications
Technical Specifications Frequency bandwidth: 2.65 Gbps (Single Link) Supporting Graphic Resolution: Supports all standard display resolutions up to WUXGA (2048 X 1080 / 1920 X 1200 @ 60Hz), UXGA, SXGA, XGA, VGA & 480i/p, 720i/p, 1080i/p) Input Connector: HDMI Female x 2 Output Connector: HDMI Female x 5 Power adapter: DC 12v, 4a Power Consumption: 13W Max... -
Page 14: Warranty Information
This warranty has no relationship to and exists independently of any warranty offered by Dealer. PureLink shall repair or replace the Product if it develops a material fault during the period of warranty, on condition that i) the Product has only been subject to normal use in a domestic or... -
Page 15: Troubleshooting
This warranty only applies to the original purchaser, and shall be the exclusive remedy to the original purchaser. PureLink shall not be liable for any damages whatsoever caused by Product or the failure of Product to perform, including incidental or consequential damages. PureLink shall not be liable for any claim made by a third party or made by the purchaser for a third party. - Page 16 4. If you are using computers, try other refresh rate settings. Most HDTV’s have refresh rate of 48Hz and computer’s video cards are usually set at higher refresh rate. Try lower refresh rates. 5. Make sure all HDMI connectors are tightly secured to all HDMI ports.
