- Page 1 UHD2-140 Owner’s Manual 1 x 4 HDMI 2.0 Distribution Amplifier PureLink E-mail: info@purelinkav.com 535 East Crescent Avenue www.purelinkav.com Ramsey, NJ 07446, USA Tel: 201.488.3232 For technical support, contact: Fax: 201.621.6118 support@purelinkav.com...
-
Page 2: Table Of Contents
Table of Contents 1-1 Package Contents 1-2 General Specification 1-3 Operation and Reliability Specifications 1-4 Main Features 1-5 Video Connection 1-6 Mechanical Specification 1-7 Technical Specification p.10 1-8 Warranty Information p.11 Manual version Release date 1/16/2017 3/07/2017... -
Page 3: Package Contents
PureLink by Dtrovision 1-1 Package Contents Please make sure all of the following items are included in the package: 1) UHD2-140 Unit 2) DC 5V 2A Power supply adapter 3) Owner’s Manual... -
Page 4: General Specification
PureLink UHD2-140 1x4 HDMI 2.0 distribution amplifier is designed to distribute a single HDMI/DVI digital signal into multiple monitor without any degradation of original signal quality or distortion of the image. In addition, a dedicated IC chipset makes UHD2-140 capable of amplifying and distributing highest quality of video signal and UHD digital contents. -
Page 5: Operation And Reliability Specifications
PureLink by Dtrovision 1-3 Operation and Reliability Specification 1. Operating Environment Temperature : 32F ~ 140F (0℃~ 60℃) Humidity : 10% ~ 80% Altitude : 3,000m Max. 2. Transit Environment Temperature : -13F ~ 140F (-25℃~ 60℃) Humidity : 5% ~ 95% Altitude : 15,000m Max. -
Page 6: Main Features
2,300 ft using our fiber optical HDMI cables. 3. HDMI (High Definition Multimedia Interface) v 2.0 UHD2-140 is consisting of HDMI input and output ports, and it is conforms to HDMI 2.0 standard. 4. HDCP 2.2 (High-bandwidth Digital Content Protection) Compliant Our HDMI distribution amplifiers are fully HDCP compliant. -
Page 7: Video Connection
Video Connection 1. Turn off the whole system before connecting. 2. Connect your video source’s HDMI output port to the UHD2-140’s HDMI input port using standard HDMI cables (not included). 3. Connect your HDMI display’s HDMI input port to UHD2-140’s HDMI output port. - Page 8 PureLink by Dtrovision UHD2-140 provides Auto EDID management system to meet today’s sophisticated digital connectivity integration environment. There is an EDID setting DIP switch on the front of the unit; EDID SETTING DIP Switch Position EDID function Dip switch 1,2,3,4 “up” position Communicate EDID with factory default at 1080p 2ch Dip switch 1 "down"...
-
Page 9: Mechanical Specification
PureLink by Dtrovision 1-6 UHD2-140 Mechanical Specification UHD2-140 Dimension: 6.6” x 3.96” x 1.58” (167 x 100.5 x 40 mm) *RS-232 Port is used to connect to PC for firmware upload... -
Page 10: Technical Specification
PureLink by Dtrovision 1-7 Technical Specification Frequency bandwidth: 18 Gbps Supporting Graphic Resolution: Supports all standard display resolutions up to UltraHD/4K 4096x2160@50/60Hz (RGB 4:4:4 YCbCr 4:4:4, 4:2:2, 4:2:0) , 480i, 576i, 720p, 1080i, 1080p@60Hz Inputs: Single HDMI Input Output: Dual HDMI Output... - Page 11 PureLink or its authorized resellers. If the product does not operate as warranted during the applicable warranty period, PureLink shall, at its option and expense, execute one of the following as necessary: 1. Repair the defective product or part 2.
