Translation of the
original user guide
USER GUIDE
*
*
Optional (Carving guide ref:
80344).
READ THE USER GUIDE CAREFULLY BEFORE USING THE TOOL
51_82029_K - 03/2015
Advertisement
Table of Contents
Related Manuals for pellenc Selion C21 HD
Summary of Contents for pellenc Selion C21 HD
- Page 1 Route de Cavaillon B.P. 47 84122 PERTUIS cedex (France) Tel : +33(0)4 90 09 47 00 Fax : +33(0)4 90 09 64 09 E-mail : pellenc.sa@pellenc.com www.pellenc.com Translation of the original user guide USER GUIDE Optional (Carving guide ref: 80344).
-
Page 2: Table Of Contents
OIL RESERVOIR ................23 «PELLENC SA» TERMS OF WARRANTY AND NON-RESPONSIBILITY CLAUSE ..... . . 24... -
Page 3: Safety Instructions
INTRODUCTION Dear Customer, Thank you for purchasing the SELION C21 HD chainsaw. Correctly used and maintained, this tool will give satisfactory performance for years to come. ENVIRONMENTAL PROTECTION Your equipment comprises numerous materials which can be valorised or recycled. Entrust these to your reseller or to an approved service centre so that they can be processed. - Page 4 SAFETY INSTRUCTIONS Work area safety 1– Keep the working area clean and well lit. Untidy or dark areas are conducive to accidents . 2– Do not operate electrical tools in an explosive atmosphere, for example where there are flammable liquids, gases or dust. Electrical tools produce sparks which can ignite dust or smoke . 3–...
-
Page 5: Safety Instructions For The Chainsaw
. Maintenance and upkeep 1– Have the tool maintained by an authorised PELLENC distributor using only identical spare parts. This will guarantee that the tool safety is maintained . SAFETY INSTRUCTIONS FOR THE CHAINSAW 1–... -
Page 6: Causes Of Kickback And How The User Can Prevent It
The second safety feature is provided by the tool’s self-diagnostic system: When the tool is first used, the SELION C21 HD checks that the electronic kick-back sensor is operational, and if this is the case, the tool can operate! Finally, the third safety feature arises from the use of OREGON low kick-back chains: if there is a kick- back, it will be less severe than with a standard chainsaw. -
Page 7: Safety Equipment
„ Keep your left arm straight for better control. „ Hold the chainsaw at your side, and not in front of you. „ Use Pellenc genuine chains and guides. „ Keep the chain, the guide and the sprocket in good working condition. -
Page 8: Safety Indications
SAFETY INDICATIONS 51_10_011C 1– Read the user guide 2– Safety goggles and a protective helmet must be worn 3– Suitable hand, fore-arm, leg and foot protection is mandatory 4– Risk of burns (motor) 5– Do not expose to rain 6– LwA sound power level guaranteed 7–... -
Page 9: Safety Measures
SAFETY MEASURES WORKING WITH TREE SERVICE CHAIN-SAWS FROM ROPE AND HARNESS Overview This annex sets out working practices aimed at reducing the risk of injury from tree service chain-saws when working at height from a rope and harness. While it may form the basis of guidance and training literature, it should not be regarded as a substitute for formal training. - Page 10 SAFETY MEASURES The ability to directly attach the saw to the harness reduces the risk of damage to equipment when moving around the tree. Always switch the saw off when it is directly attached to the harness. The saw should only be attached to the recommended attachment points on the harness.
- Page 11 SAFETY MEASURES Gaining a good footing at the working position can be assisted by the use of a temporary foot stirrup created from an endless sling (see Figure E4). One-handed use of the chain-saw Operators should not use tree service chain-saws one-handed when work position is unstable or in preference to a handsaw when cutting small diameter wood at the branch tips.
-
Page 12: Description And Technical Characteristics
According to use and battery type Chain oil reservoir capacity 25 cm Useful cutting length / chain guide 30 cm (12’’) / specific to Pellenc Chain Type / Pitch / Gage 25AP / 6.35 mm (1/4’’) / 1.3 mm (0.05’’) Sprocket 11 teeth 1/4’’... -
Page 13: Putting The Tool Into Service
CHAIN LUBRICATING SYSTEM Reasonable oil consumption! Oil consumption has been significantly reduced by the electronic control of the oil flow. This is a PELLENC innovation. 1– Use special guide and chain oil (P/No. 85920). 2– Carefully pour the guide and chain oil into the reservoir. -
Page 14: Starting
1 to 2 minutes. Check the chain tension after running in (see page 23). The tool is equipped with a Pellenc-designed electric motor. The motor maintains a constant speed, both off load and when cutting. Allow the chainsaw to cut without pressing excessively. -
Page 15: Starting And Use
You can permanently lock it in position using the retractable wrench (PELLENC innovation). The automatic chain tensioning along with the PELLENC retractable wrench can also be used to retighten the guide in a few seconds: no need for additional wrenches! 51_08_025A Make sure that the chain tension is correct by pulling the chain. -
Page 16: Installing The Chain Guide
Simplified chain maintenance! No need for an additional wrench to remove and reinstall the chain, PELLENC’s innovative retractable wrench system can be used to tighten the chain in a few seconds. Loosen the chain guard (10) nut by 3 turns. -
Page 17: Checking And Replacing The Sprocket
STARTING AND USE Adjust the tension as often as necessary. Check the tension by pulling the chain in the middle of the guide: 1 to 3 drive links should appear. 51_08_025A CHECKING AND REPLACING THE SPROCKET Remove the chain guide and the chain. Remove the circlip and remove the sprocket. -
Page 18: The Four Basic Rules
STARTING AND USE THE FOUR BASIC RULES „ RULE No. 1 The chain must be correctly tensioned. See page 23 51_07_021A „ RULE No. 2 The chain must be well lubricated. Constant lubrication of the guide, the chain and the sprocket is vital. -
Page 19: Servicing
SERVICING CLEANING Keep the tool clean by cleaning it frequently using a damp cloth and compressed air. Pay particular attention to the parts in contact with the wood (chain, guide). 51_08_031A CAUTION: Never use solvents (Trichlorethylene, White Spirit, gasoline, etc) to clean the tool. SERVICING INTERVALS Visual check of the tool Functional check of the safety trigger... -
Page 20: Replacing The Chain And The Guide
Before working on the tool, check that the On / Off switch is in the off position «0» and disconnect the battery power lead. WARNING: Never use a chain or a guide other than that specified by PELLENC, otherwise there is a risk of personal injury. -
Page 21: General Instructions For Sharpening The Cutters
GENERAL INSTRUCTIONS FOR SHARPENING THE CUTTERS SHARPENING THE CUTTERS USING A ROUND FILE „ As shown on the diagram, place a file holder on the top platen and the depth limiter of the cutter. Direction to be followed File holder =1/5 of the Ø... -
Page 22: Adjusting The Depth Limiters
„ Check the depth limiters again. If the depth limiters need adjusting again, follow the instructions on page 29. Note: Do not file the top of the drive links or the side links fitted with an anti-kickback guard. ADJUSTING THE DEPTH LIMITERS Sharpening kit P/No. -
Page 23: Maintenance
„ After reducing the height of the depth limiters, round off the angle to maintain the original shape of the depth limiters. Note: On chains with drive links equipped with anti- kickback guards, it may be necessary to take the chain out of the guide in order to file the depth limiters correctly. -
Page 24: Pellenc Sa» Terms Of Warranty And Non-Responsibility Clause
As concerns parts or equipment that are not manufactured by PELLENC sa, in particular ball screw, battery, etc., the warranty is limited to that of the suppliers to PELLENC sa. Normal wear parts worn out as the result of use are never under warranty. -
Page 25: Ec" Declaration Of Conformity
"EC" DECLARATION OF CONFORMITY MACHINES DIRECTIVE 2006/42/CE, APPENDIX IIA. (ONLY CONCERNS EUROPE) MANUFACTURER PELLENC S.A. ADDRESS QUARTIER NOTRE-DAME ROUTE DE CAVAILLON - B.P. 47 84122 PERTUIS CEDEX (FRANCE) PERSON/ENTITY AUTHORISED TO COMPILE THE TECHNICAL PELLENC S.A. DOSSIER ADDRESS QUARTIER NOTRE-DAME ROUTE DE CAVAILLON - B.P.
