EUROCOM ARMADILLO 2 W840AU Service Manual page 37

6. Carefully lift up the keyboard
7. Reverse the process to install a new keyboard.
8. Replace the center cover module as shown
d.
8
off the computer (Figure 9d).
8
(Figure 9e).
e.
16
Disassembly
Figure 9
Keyboard Removal
(cont'd.)
d. Remove the keyboard.
e. Remove the keyboard
shielding plate.
Removing the Keyboard 2 - 13
