Assembly 31.1: HCIT
Asm- Part Units/
Index number option
31.1–1 40X2145
2 40X2143
3 40X2092
4
5 40X2094
6 40X2141
7 40X2142
8 40X2093
9 40X2144
10 40X2146
11 40X2100
12 40X2099
13 40X2106
14 40X2109
NS 40X2101
NS 40X2102
NS 40X2104
NS 40X2107
NS 40X2130
NS 40X2132
NS 40X2140
Units/
Description
FRU
1 1 Rear cover
1 1 Right side cover
2 1 Caster, movable
16 16 Screw type 312/322/412/423, parts packet, 40X1691
4 1 F adjuster
1 1 Front cover
1 1 Cover, main CA
2 1 Caster, fixed
1 1 Left side cover
1 1 Upper left side jam cover
1 1 Locating pin, options front right
1 1 Locating pin, options rear left
1 1 Options autoconnect cable assembly
1 1 Options cable mounting plate
1 1 Feed unit special sensors cable
1 1 Feed unit sensors cable
1 1 Elevator motor cable
1 1 Magnetic latch
1 1 Tray present lever
9 1 Cable clamp
1 1 Stabilizer kit with mounting screws
